Fig 3-9
3. INSTALLATION METHOD
Putty
Putty
Putty
Trap
Trap
Trap
Fig 3-10
IMPORTANT: All the pictures
in this manual are for
illustration purposes only.
Your wire controller may
dier slightly.
8. Reattach the wire controller’s upper part
While adjusting and mounting the upper case, avoid clamping the
wiring during installation. (Fig 3-10)
NOTE: DO NOT allow water to enter the remote control.
Use the trap and putty to seal the wires.
