Page 3
ECONOMIZER INSTALLATION
ECONOMIZER
FIGURE 4
RETURN AIR
OPENING
UNIT
B7
DAMPER MOTOR
A2 SENSOR
(UNITS WITH DDC
CONTROL)
RT16
SENSOR
SMOKE DETECTOR
(WHEN EQUIPPED)
