Lennox LGH 036

Page 5
FIGURE 7
ASSEMBLE HOODS
INSTALL LOWER BRACKET
BEFORE INSTALLING
BIRDSCREEN
BIRDSCREEN
SECURE TOP BRACKET
WITH SCREW AFTER
BIRDSCREEN IS IN PLACE
GED INSTALLED IN HOODS WHEN POWER
EXHAUST IS PRESENT. GED INSTALLED IN
POWER EXHAUST LOCATION WHEN UNIT
IS NOT EQUIPPED WITH POWER EXHAUST.
SEE FIGURE 5.
OUTDOOR AIR HOOD
EXHAUST OR LOWER HOOD
LOWER HOOD INSTALLED
ONLY WHEN ECONOMIZER IS
EQUIPPED WITH A GED
