Lennox LGH094U - Refrigerant Circuit Diagrams - Ultra High Efficiency; Optional Ultra High Efficiency Units with Fin;Tube Coil

Page 33
PLUMBING, COMPRESSOR AND REFRIGERANT CIRCUITS DETAIL
(OPTIONAL ULTRA HIGH EFFICIENCY UNITS WITH FIN/TUBE COIL)
COMPRESSOR
2
COMPRESSOR
1
INDOOR COIL
OUTDOOR COILS
(1 CIRCUIT)
DRIER
FIGURE 14
COMMON
DISCHARGE LINE
COMMON
SUCTION LINE
S8
COMPRESSOR 2 HIGH
TEMPERATURE LIMIT
S5
COMPRESSOR 1 HIGH
TEMPERATURE LIMIT
A185
PRESSURE
TRANSDUCER
S87
LOW PRESSURE
SWITCH
COMPRESSOR
2
COMPRESSOR
1
DISCHARGE
LINE
LIQUID LINE
DISCHARGE
LINE
LIQUID LINE
