LGH/LCH240 CHARGING CURVE CIRCUIT 3
100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
Suction Pressure
(p
si
g)
115°
105°
95°
85°
75°
65°
Outdoor Temperature (°F)
70
80
90
100
110
120
130
LGH/LCH240 CHARGING CURVE CIRCUIT 4
100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
Suction Pressure (psig)
115°
105°
95°
85°
75°
65°
Outdoor Temperature (°F)
70
80
90
100
110
120
130
