Lennox LGH240H Installation Instructions

Page 37
507124-04 3/2016
TABLE 14
LG/LC Series 210H Std.
Outdoor
Coil En
tering
Air Temp
Circuit 1 Circuit 2 Circuit 3
Dis.
+
10
psig
Suc.
+
5
psig
Dis.
+
10
psig
Suc.
+
5
psig
Dis.
+
10
psig
Suc.
+
5
psig
65F* 246 138 252 142 264 138
75F 284 142 294 145 306 140
85F 326 145 335 147 348 142
95F 373 148 380 149 393 144
105F 422 150 430 151 441 145
115F 472 153 482 154 492 148
TABLE 15
LG/LC Series 210H Reheat
Outdoor
Coil En
tering
Air Temp
Circuit 1 Circuit 2 Circuit 3
Dis.
+
10
psig
Suc.
+
5
psig
Dis.
+
10
psig
Suc.
+
5
psig
Dis.
+
10
psig
Suc.
+
5
psig
65F* 258 136 264 141 264 138
75F 296 140 306 144 306 140
85F 338 143 347 146 348 142
95F 385 146 392 148 393 144
105F 434 148 442 150 441 145
115F 484 151 494 153 492 148
TABLE 16
LG/LC Series 240H Std.
Outdoor
Coil En
tering
Air Temp
Circuit 1 Circuit 2 Circuit 3 Circuit 4
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
65F* 255 137 246 132 260 141 252 135
75F 291 140 284 137 298 144 290 137
85F 332 142 325 140 340 146 331 139
95F 378 145 371 142 385 148 377 141
105F 428 148 421 145 436 150 428 143
115F 481 151 473 148 488 153 479 145
TABLE 17
LG/LC Series 240H Reheat
Outdoor
Coil En
tering
Air Temp
Circuit 1 Circuit 2 Circuit 3 Circuit 3
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
65F* 270 13 261 130 260 141 252 135
75F 306 137 299 135 298 144 290 137
85F 347 140 340 137 340 146 331 139
95F 393 143 386 140 385 148 377 141
105F 443 145 436 143 436 150 428 143
115F 496 148 488 145 488 153 479 145
TABLE 18
LG/LC Series 240U
Outdoor
Coil En
tering
Air Temp
Circuit 1 Circuit 2
Dis. +10
psig
Suc. +5
psig
Dis. +10
psig
Suc. +5
psig
65F 251 127 262 128
75F 290 132 303 133
85F 331 135 347 136
95F 376 137 394 139
105F 426 141 443 142
115F 479 144 495 145
TABLE 19
LG/LC Series 300S Std.
Outdoor
Coil En
tering
Air Temp
Circuit 1 Circuit 2 Circuit 3 Circuit 4
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
°65F* 272 129 273 128 280 129 277 127
75F 311 132 303 131 321 131 317 129
85F 357 134 349 133 367 133 363 130
95F 403 137 397 137 418 135 406 134
105F 451 139 453 140 475 138 471 136
115F 502 142 506 142 532 144 529 140
TABLE 20
LG/LC Series 300S Reheat
Outdoor
Coil En
tering
Air Temp
Circuit 1 Circuit 2 Circuit 3 Circuit 4
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
Dis.
+
10
psi
g
Suc
. +
5
psi
g
°65F* 285 128 284 128 280 129 277 127
75F 324 132 315 130 321 131 317 129
85F 368 134 358 132 367 133 363 130
95F 418 136 406 136 418 136 406 135
105F 466 138 462 138 475 138 471 136
115F 517 141 515 141 532 144 529 140
