Lennox LGH240H - Page 70

Page 70
110120 130 140 150 160170
Suction Pressure (psig)
115°
105°
95°
85°
75°
65°
Outdoor Temperature (°F)
70
80
90
100
110
120
130
180
LGH/LCH240 CAV/STAGED REHEAT CHARGING CURVES CIRCUIT 3
110120 130 140 150 160 170
Suction Pressure (psig)
115°
105°
95°
85°
75°
65°
Outdoor Temperature (°F)
70
80
90
100
110
120
130
LGH/LCH240 CAV/STAGED REHEAT CHARGING CURVES CIRCUIT 4
