Lennox LGT150H Installation Instructions

Page 20
TABLE 4 581114-01
LGT/LCT092
Normal Operating Pressures
Outdoor Coil Entering Air Temperature
65 F 75 F 85 F 95 F 105 F 115 F
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Suct
(psig)
Disc
(psig)
Circuit 1
101 230 103 266 106 312 108 361 111 436 114 514
108 233 111 268 113 313 116 366 119 435 122 512
126 238 128 271 131 315 133 371 136 433 139 508
147 244 149 275 152 317 154 376 157 431 159 505
Circuit 2
120 236 122 273 124 315 126 364 128 418 129 478
129 239 131 275 133 318 135 366 137 420 139 480
147 245 150 281 153 323 155 370 157 424 160 484
168 252 171 287 174 328 177 376 179 429 182 488
70
80
90
100
110
120
Suction Pressure (psig)
Outdoor Temperature (°F)
115°
105°
95°
85°
75°
65°
Charging Curves
Circuit 1
Circuit 2
60
100 110 120 130 140 150 160 170 180
