Page 32

LHT/LDT156, 180, 240

FIGURE 27

INSTALL IONIZER

SLIDE IONIZER BRACKET

BETWEEN UPPER AND LOWER

FILTER BRACKET U-CHANNELS

20 TON SHOWN

(5 IONIZERS)

LOWER FILTER

BRACKET

U-CHANNEL

UPPER FILTER

BRACKET

U-CHANNEL

IONIZER

BRACKET

INDOOR COIL

ONE EDGE

PROTECTOR ON

IONIZER BRACKET

REMOVE THE

SCREW SECURING

THE BOTTOM OF

THE UPPER FILTER

RACK BRACKET

REMOVE THE SCREW

SECURING THE TOP

OF THE UPPER FILTER

RACK BRACKET

TWO EDGE

PROTECTORS ON

FILTER RACK
