Page 35
508336-01 4/2023
TABLE 15 - 581182-01
Staged Blower Parameters
Para
meter
Factory Setting
Field
Setting
Description
156H 180H 240H
Note: Any changes to Smoke CFM setting must be adjusted before the other CFM settings.
Use SETTINGS > RTU OPTIONS > EDIT PARAMETERS
12
5200
CFM
6000
CFM
8000
CFM
CFM Blower CFM during smoke detection.
SETUP > TEST & BALANCE (can also use SETTINGS > RTU OPTIONS > BLOWER > SPEEDS)
17
3380
CFM
3900
CFM
5200
CFM
CFM
Blower CFM during COOLING LOW operation.
14
4675
CFM
5400
CFM
7200
CFM
CFM
Blower CFM during COOLING HIGH operation.
13
6000
CFM
6000
CFM
8000
CFM
CFM
Blower CFM during Heating operation.
18
5200
CFM
6000
CFM
8000
CFM
CFM
Blower CFM during ventilation.
SETUP > TEST & BALANCE (can also use SETTINGS > RTU OPTIONS > DAMPER)
9 0% 0% 0% % Damper min. position during LOW blower operation.
132
0% 0% 0% % Damper min. position during HIGH blower operation.
215
50% 50% 50% % Min. damper % for stg 1 power exhaust operation.
SETTINGS > RTU OPTIONS > EDIT PARAMETERS
29 101% 101% 101% %Open
Damper minimum position during G blower operation. (Setting parameter 29 to “101” dis
ables parameter 29 and passes control to parameter 9 or 132)
219 75% 75% 75% % Min. damper % for stg 2 power exhaust operation.
216 10% 10% 10% % Deadband % for stage 1 power exhaust operation.
220 10% 10% 10% % Deadband % for stage 2 power exhaust operation.
224 100 100 100 Sec Stage 1 power exhaust off-delay in seconds.
30 70% 70% 70% %Speed Minimum blower speed % for stage 2 power exhaust operation.
