Service Manual
Technical Information
10
3.Outline Dimension Diagram
Unit: mm
Model W(mm) H(mm) D(mm)
LNWR21X 560 375 668
LNWR39X 660 420 700
LNWR53X 660 420 770
LNWR59X 660 420 770
Over
500
W D
H
Over
150
Over
150
