Service Manual
Technical Information
11
4.Refrigerant System Diagram
OUTDOOR COILS
HOT DISCHARGED AIR
COOLED AIR
COMPRESSOR
AXIAL FAN
CENTRIFUGAL
OR CROSS FAN
CAPILLARY
REFRIGERANT FLOW DIRECTION
NOTES:
COOLING MODE
HEATING MODE
HOT AIR
COOLED AIR
INDOOR COILS
