ELECTRIC HEAT DATA — LRP14AC Only (Contd.)
Model No.LRP14AC42 LRP14AC48 LRP14AC60
208/230V 208/230V 208/230V
Compressor
Rated Load Amps 15.9 18 24.3
Locked Rotor Amps85 117 144.2
Outdoor Fan
Motor
Full Load Amps 1.7 1.7 1.7
Locked Rotor Amps3.2 3.2 3.2
Indoor
Blower Motor
Rated Load Amps 2.8 2.8 7.6
Locked Rotor Amps5.4 6.8 - - -
1
Maximum
Overcurrent
Protection
Voltage 208V 240V 208V 240V 208V 240V
Unit only, no electric heat 40 40 40 40 60 60
5 kW 30 30 30 30 35 35
7.5 kW 40 45 40 45 45 50
10 kW 50 60 50 60 60 60
15 kW
Circuit 1 50 60 50 60 60 60
Circuit 225 30 25 30 60 60
20 kW
Circuit 1 50 60 50 60 60 60
Circuit 250 60 50 60 60 60
1
Maximum Overcurrent
Protection with Optional
Single-Point Power
Supply
5 kW 40 40 40 40 60 60
7.5 kW 40 45 40 45 60 60
10 kW 50 60 50 60 60 60
15 kW 80 90 80 90 80 90
20 kW 100 110 100 110 100 125
2
Minimum
Circuit
Ampacity
Unit only, no electric heat 24.4 24.4 26.9 26.9 38.9 38.9
5 kW 25.4 28.8 25.4 28.8 30.2 33.6
7.5 kW 36.7 41.9 36.7 41.9 41.5 46.7
10 kW 47.9 54.9 47.9 54.9 52.7 59.7
15 kW
Circuit 1 47.9 54.9 47.9 54.9 52.7 59.7
Circuit 2 22.6 26 22.6 26 22.6 26
20 kW
Circuit 1 47.9 54.9 47.9 54.9 52.7 59.7
Circuit 2 45.1 52.1 45.1 52.1 45.1 52.1
2
Minimum Circuit
Ampacity with Optional
Single-Point Power
Supply
5 kW 25.4 28.8 26.9 28.8 38.9 38.9
7.5 kW 36.7 41.9 36.7 41.9 41.5 46.7
10 kW 47.9 54.9 47.9 54.9 52.7 59.7
15 kW 70.5 80.9 70.5 80.9 75.3 85.7
20 kW 93 107 93 107 97.8 111.8
NOTE - All units have a minimum Short Circuit Current Rating (SCCR) of 5000 amps.
NOTE - Extremes of operating range are plus and minus 10% of line voltage.
1
HACR type breaker or fuse.
2
3
A separate compressor circuit is required.
ELECTRICAL DATA — LRP14GE Only
Model No.LRP14GE24 LRP14GE30 LRP14GE36 LRP14GE42 LRP14GE48 LRP14GE60
208/230V 208/230V 208/230V
1
Maximum Overcurrent Protection (amps) 25 30 30 40 40 60
2
Minimum Circuit Ampacity 16.7 18.7 20.6 24.4 26.9 38.9
Compressor
Rated Load Amps 11.2 12.8 14.1 15.9 17.9 23.7
Locked Rotor Amps60.8 64 72.2 85 96 152.5
Outdoor Coil
Fan Motor
Full Load Amps 1.0 1.0 1.0 1.7 1.7 1.7
Locked Rotor Amps1.9 1.9 1.9 3.2 3.2 3.2
Indoor
Blower Motor
Full Load Amps 1.7 1.7 2.0 2.8 2.8 7.6
Locked Rotor Amps 3.9 3.9 4.4 5.4 6.8 - - -
NOTE - All units have a minimum Short Circuit Current Rating (SCCR) of 5000 amps.
NOTE - Extremes of operating range are plus and minus 10% of line voltage.
1
HACR type breaker or fuse.
2
