ELECTRICAL DATA – LRP14GN

Line voltage data - 60Hz 1 phase 208/230V 208/230V 208/230V 208/230V 208/230V 208/230V

Maximum Overcurrent Protection (MOCP) amps

20 25 35 40 40 60

Minimum Circuit Ampacity (MCA) 14.4 18.2 22.7 27.5 28.7 38.9

Compressor Rated load amps 8.6 10.6 15.7 15.9 16.9 26.4

Locked rotor amps 63.5 67 72.2 112.39

52.5

Outdoor Coil

Fan Motor

Full load amps 1.0 1.01.0 1.71.7 1.7

Locked rotor amps 1.9 1.91.9 3.23.2 3.2

Indoor Blower

Motor

Full load amps 2.8 4.14.1 667.6

Locked rotor amps 3.9 3.94.4 5.46.8 - - -

NOTE-Extremes of operating range are plus and minus 10% of line voltage.

Sound Rating Number rated in accordance with test conditions included in AHRI Standard 270.

HACR type circuit breaker or fuse.

Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.

Model No. LRP14GN24LRP14GN30 LRP14GN36 LRP14GN42 LRP14GN48 LRP14GN60

ELECTRICAL DATA — LRP16GE Only

Model No.LRP16GE24 LRP16GE36 LRP16GE48 LRP16GE60

208/230V

Maximum Overcurrent Protection (amps) 25 35 50 60

Minimum Circuit Ampacity 17.0 22.7 31.2 41.7

Compressor

Rated Load Amps 11.7 15.3 21.2 28.8

Locked Rotor Amps 58.3 83.0 104.0 152.9

Outdoor Coil

Fan Motor

Full Load Amps 1.0 1.0 1.7 1.7

Locked Rotor Amps1.9 1.9 3.2 3.2

Indoor

Blower Motor

Full Load Amps 1.1 2.3 3.1 4.0

Locked Rotor Amps 4.3 4.3 6.8 9.1

NOTE - All units have a minimum Short Circuit Current Rating (SCCR) of 5000 amps.

NOTE - Extremes of operating range are plus and minus 10% of line voltage.

HACR type breaker or fuse.
