Page 28
80 DB / 67 WB Deg.
Return Air
Air Temperature Entering Evaporator Coil, Degree F
COOLING
INPUT
(1000 BTU)
Pressure 65° 70° 75° 80° 82° 85° 90° 95° 100° 105° 110° 115°
24
Suction
141 142 142 143 143 144 145 147 148 149 149 150
36 132 134 136 137 138 139 140 142 144 145 147 148
48 136 138 140 142 143 144 145 147 148 149 150 151
60 134 135 137 138 139 140 141 142 144 145 147 148
24
Liquid
237 257 278 298 306 320 343 366 392 419 445 471
36 239 260 280 301 309 323 347 370 397 424 451 478
48 243 264 284 305 313 327 351 374 401 428 454 481
60 249 270 292 313 322 337 361 385 414 443 472 501
Table 6. Cooling Performance - HP Models
