Page 29
70 Deg. F Return Air Air Temperature Entering Evaporator Coil, Degree F
COOLING
INPUT
(1000 BTU)
Pressure 0° 5° 10° 17° 20° 25° 30° 35° 40° 47° 50° 55° 60°
24
Suction
28 36 44 56 61 69 78 86 94 106 113 124 135
36 26 33 40 50 54 61 68 75 83 95 103 117 131
48 28 36 43 53 57 65 72 79 89 102 107 116 125
60 31 39 46 56 60 68 75 82 89 99 106 117 128
24
Liquid
264 271 279 289 294 301 309 316 324 335 340 348 357
36 272 282 291 305 311 321 330 340 348 359 365 374 383
48 283 291 298 308 312 320 327 334 342 353 358 367 376
60 285 295 304 316 321 330 339 348 357 370 375 383 392
Table 7. Heating Performance - HP Models
