Lennox MHA024S4S-1P - 7.2. Capacities, Dimensions, and Clearances

16
Design Pressure PSIG 550 / 340 550 / 340 550 / 340 550 / 340
Shipping
Data
Net/Shippingweight(lbs.)(115V) 67 / 72 71 / 77 --- ---
(208/230V) 67 / 72 67 / 73 80 / 86 106 / 113
ELECTRICAL DATA
Electrical Characteristics - 60 Hz - 1 Phase 115V 208/230V 115V 208/230V 208/230V 208/230V
1
MaximumOvercurrentProtection(amps) 20 15 20 15 20 25
2
Minimumcircuitampacity 16 10 15 15 15 20
CompressorRatedloadamps 11.5 6.4 10.1 6.8 10.0 15.0
Outdoor Fan Motor Ratedloadamps 0.6 0.5 0.55 0.45 0.5 0.6
Output-W 34 34 34 34 34 115
NOTE-Extremesofoperatingrangeareplusandminus10%oflinevoltage.
1
HACRtypecircuitbreakerorfuse.
2
RefertoNationalorCanadianElectricalCodemanualtodeterminewire,fuseanddisconnectsizerequirements.
7.3. Cooling and Heating Capacities
7.3.1. Cooling - 009 (115V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb / Wet Bulb)
65°F / 54°F 70°F / 59°F 75°F / 63°F 80°F / 67°F
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
–13 7.47 5.29 7.90 5.59 8.29 5.97 8.64 6.22
–5 7.99 5.63 8.45 5.96 8.96 6.53 9.29 6.61
–4 8.25 5.69 8.72 6.01 9.05 6.25 9.48 6.45
0 8.73 5.94 9.13 6.21 9.63 6.55 9.98 6.73
5 8.99 6.21 9.56 6.61 9.93 6.82 10.39 7.17
15 9.03 6.39 9.61 6.80 10.08 7.19 10.50 7.42
25 9.22 6.54 9.65 6.84 10.23 7.28 10.60 7.60
35 9.37 6.57 9.74 6.84 10.23 7.26 10.71 7.56
45 9.30 6.85 9.95 7.33 10.43 7.80 10.81 7.94
55 9.50 7.33 9.99 7.71 10.43 7.90 10.92 8.27
65 9.65 6.82 10.14 7.17 10.64 7.52 11.02 7.79
75 9.57 6.88 10.18 7.32 10.63 7.64 11.13 8.00
85 9.77 7.12 10.22 7.44 10.78 7.85 11.23 8.18
95 9.89 6.94 10.35 7.25 10.91 7.65 11.31 7.93
105 9.29 6.74 9.78 7.09 10.26 7.44 10.74 7.79
110 8.59 6.70 9.09 7.09 9.64 7.52 9.99 7.79
115 8.08 6.87 8.55 7.27 8.87 7.54 9.29 7.90
122 7.48 6.66 7.78 6.92 8.16 7.26 8.55 7.61
