Lennox ML193UH110XE48C Installation Instructions

Page 54
Blower Data
ML193UH110XE60C PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Di󰀨erent Blower Speeds
Bottom Return Air, Side Return Air with Return Air from
Both Sides or Return Air from Bottom and One Side.
Single Side Return Air − Air volumes in bold require
Optional Return Air Base and eld fabricated transition
to accommodate 20 x 25 x 1 in. air lter in order to
maintain proper air velocity.
High
(Black)
Med-High
(Brown)
Medium
(Blue)
Med-Low
(Yellow)
Low
(Red)
High
(Black)
Med-High
(Brown)
Medium
(Blue)
Med-Low
(Yellow)
Low
(Red)
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 2150 624 1915 436 1755 345 1650 280 1480 201 2175 607 1930 412 1760 330 1645 271 1475 199
0.10 2120 633 1880 441 1715 353 1605 288 1435 210 2135 614 1885 421 1705 342 1595 280 1415 207
0.20 2085 648 1830 455 1665 362 1560 298 1360 220 2085 628 1830 437 1670 351 1545 293 1370 218
0.30 2040 663 1795 468 1630 374 1515 317 1325 229 2035 647 1790 451 1625 364 1500 308 1315 227
0.40 2005 675 1760 482 1585 386 1470 327 1270 244 1995 657 1755 469 1590 378 1460 319 1275 240
0.50 1965 688 1710 496 1540 399 1425 336 1230 251 1985 674 1725 478 1545 391 1410 329 1225 250
0.60 1935 705 1680 507 1510 408 1390 347 1180 263 1925 687 1675 494 1495 401 1375 343 1170 257
0.70 1885 715 1635 521 1485 425 1345 359 1140 271 1900 698 1635 506 1450 413 1330 351 1125 270
0.80 1855 735 1600 534 1440 426 1305 367 1085 279 1850 711 1605 520 1415 430 1285 363 1075 281
