Page 17
ML296UHV HEATING COMPONENTS
FIGURE 11
Intake Air Top Cap
Sensor
Rollout Switch
Rollout Switch
Burner Assembly
Ignitor
Manifold And Gas Orifices
Two-Stage Gas Valve
Burner Box Cover
