Page 2
SPECIFICATIONS
Gas
Heating
Performance
Model No. ML296UH045XV36B ML296UH070XV36B
AHRI Reference No. N/A N/A
1
AFUE 96% 96%
High
Fire
Input - Btuh 44,000 66,000
Output - Btuh 42,000 62,000
Temperature rise range - °F 35 - 65 50 - 80
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 10.0 3.5 / 10.0
Low
Fire
Input - Btuh 29,000 43,000
Output - Btuh 28,000 41,000
Temperature rise range - °F 20 - 50 25 - 55
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
1.7 / 4.9 1.7 / 4.9
High static - in. w.g. Heating 0.8 0.8
Cooling 1.0 1.0
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 3/4 3/4
with furnished 90° street elbow 3/4 slip x 3/4 Mipt 3/4 slip x 3/4 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT
Indoor
Blower
Wheel nominal diameter x width - in. 10 x 9 10 x 9
Motor output - hp 1/2 1/2
Tons of add-on cooling 2 - 3 2 - 3
Air Volume Range - cfm 485 - 1370 500 - 1365
Electrical Data Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 7.7 7.7
Maximum overcurrent protection 15 15
Shipping Data lbs. - 1 package 130 138
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization Eciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized furnaces.
Gas
Heating
Performance
Model No. ML296UH090XV48C ML296UH110XV60C
AHRI Reference No. N/A N/A
1
AFUE 96% 96%
High
Fire
Input - Btuh 88,000 110,000
Output - Btuh 84,000 106,000
Temperature rise range - °F 45 - 75 45 - 75
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
3.5 / 10.0 3.5 / 10.0
Low
Fire
Input - Btuh 57,000 72,000
Output - Btuh 55,000 70,000
Temperature rise range - °F 30 - 60 35 - 65
Gas Manifold Pressure (in. w.g.)
Nat. Gas / LPG/Propane
1.7 / 4.9 1.7 / 4.9
High static - in. w.g. Heating 0.8 0.8
Cooling 1.0 1.0
Connections
in.
Intake / Exhaust Pipe (PVC) 2 / 2 2 / 2
Gas pipe size IPS 1/2 1/2
Condensate Drain Trap (PVC pipe) - i.d. 3/4 3/4
with furnished 90° street elbow 3/4 slip x 3/4 Mipt
3/4 slip x 3/4 Mipt
with eld supplied (PVC coupling) - o.d. 3/4 slip x 3/4 MPT 3/4 slip x 3/4 MPT
Indoor
Blower
Wheel nominal diameter x width - in. 11 x 11 11 x 11
Motor output - hp 3/4 1
Tons of add-on cooling 2.5 - 4 3 - 5
Air Volume Range - cfm 680 - 1770 790 - 1955
Electrical Data Voltage 120 volts - 60 hertz - 1 phase
Blower motor full load amps 10.1 12.8
Maximum overcurrent protection 15 20
Shipping Data lbs. - 1 package 163 174
NOTE - Filters and provisions for mounting are not furnished and must be eld provided.
1
Annual Fuel Utilization Eciency based on DOE test procedures and according to FTC labeling regulations. Isolated combustion system rating for non-weatherized furnaces.
