BLOWER DATA
ML296UH045XV36B BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
“ADJUST”
Switch
Positions
Speed Switch Positions
Second Stage “HEAT” Speed - cfm Second Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 780 880 990 1010 920 1065 1205 1340
1
NORM 705 795 905 925 815 985 1110 1245
— 640 715 805 810 745 890 1020 1130
“ADJUST”
Switch
Positions
First Stage “HEAT” Speed - cfm First Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 705 795 905 925 610 760 845 975
1
NORM 645 725 810 815 550 680 770 880
— 570 655 735 750 465 610 720 775
1
Factory default jumper setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT speed position.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed
position. Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position - minimum
500 cfm. Lennox Harmony III™ Zoning System Applications - Minimum blower speed is 453 cfm.
BLOWER DATA
ML296UH070XV36B BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
“ADJUST”
Switch
Positions
Speed Switch Positions
Second Stage “HEAT” Speed - cfm Second Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 965 1130 1255 1400 860 1060 1215 1365
1
NORM 880 990 1140 1295 810 960 1130 1265
— 810 890 1030 1170 705 840 1005 1140
“ADJUST”
Switch
Positions
First Stage “HEAT” Speed - cfm First Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 940 1070 1195 1345 600 740 840 970
1
NORM 830 965 1100 1235 555 665 770 855
— 755 840 975 1130 500 600 680 790
1
Factory default jumper setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT speed position.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed
position. Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position - minimum
500 cfm. Lennox Harmony III™ Zoning System Applications - Minimum blower speed is 453 cfm.
