Lennox ML296UHV(X) Series User Manual

Page 6
BLOWER DATA
ML296UH090XV48C BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR, RETURN AIR FROM BOTH SIDES OR RETURN AIR FROM BOTTOM AND ONE SIDE
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
“ADJUST”
Switch
Positions
Speed Switch Positions
Second Stage “HEAT” Speed - cfm Second Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 1230 1310 1360 1605 1165 1375 1580 1770
1
NORM 1115 1195 1255 1455 1075 1265 1440 1645
— 1005 1070 1130 1335 935 1145 1320 1465
“ADJUST”
Switch
Positions
First Stage “HEAT” Speed - cfm First Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 1165 1250 1315 1520 840 1005 1155 1315
1
NORM 1075 1140 1195 1405 780 915 1045 1190
— 935 1030 1065 1285 690 835 955 1070
1
Factory default jumper setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT speed position.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed
position. Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position - minimum
500 cfm. Lennox Harmony III™ Zoning System Applications - Minimum blower speed is 453 cfm.
BLOWER DATA
ML296UH090XV48C BLOWER PERFORMANCE (less lter)
SINGLE SIDE RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
“ADJUST”
Switch
Positions
Speed Switch Positions
Second Stage “HEAT” Speed - cfm Second Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 1210 1275 1320 1555 1140 1340 1525 1725
1
NORM 1115 1175 1230 1400 1040 1235 1395 1565
— 990 1070 1125 1295 910 1120 1275 1400
“ADJUST”
Switch
Positions
First Stage “HEAT” Speed - cfm First Stage “COOL” Speed - cfm
D
1
C B A D C B
1
A
+ 1140 1230 1280 1455 820 1005 1135 1290
1
NORM 1040 1135 1180 1370 755 880 1025 1150
— 910 1000 1075 1250 680 815 925 1065
1
Factory default jumper setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT speed position.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed
position. Continuous Fan Only speed is approximately 38% of the same second stage COOL speed position - minimum
500 cfm. Lennox Harmony III™ Zoning System Applications - Minimum blower speed is 453 cfm.
