Step 4. Removethescrewsofthefrontpanelandthen
removethefrontpanel.
Front Panel
Step 5. Removethescrewfromthewatercollectorcover.
Water Collection Cover
Step 6. Removethescrewsontherearcoilguardand
thenremovethecoilguard.
Front Cover
Step 7. Removethescrewsfromtherightpanelandthen
removepanel.
Right Panel
17.2.2. Panel Plate (MWHA024S4)
Step 1. Turnofftheairconditionerandthepower
breaker.
Step 2. Removethescrewsthatsecurethehandleand
thenremovethehandle.
Step 3. Removethescrewsfromthetopcoverandthen
remove.Oneofthescrewsislocatedunderneath
thehandle.
