NEOSYS NAC 680 760 840 960 1080
kW
702,6 774,7 859,1 979,8 1061,9
251,3 298,2 304,6 348,7 403,8
EER
(2)
2,80 2,60 2,82 2,81 2,63
ESEER
(3)
4,15 3,91 4,21 4,01 4,0
4,14 4,14 4,22 4,11 4,11
% 163 163 166 162 162
5,05 5,03 5,01 5,04 5,01
3,60 3,50 3,50 3,60 3,60
4
kg
22,4/19,3/
22,4/19,3
22,4/19,4/
22,4/19,4
34 34 34
10 10 12 12 12
%
9-18-30-41-
50-59-70-82-
91-100
10-20-30-40-
50-60-70-80-
90-100
8-15-24-33-
41-48-58-67-
74-82-91-100
8-17-25-33-
42-50-58-67-
75-83-92-100
8-15-24-33-41-48-
58-67-74-82-91-
100
[(6,8x3) +
(6,3x2)] x 2
[(6,3x3) +
(6,3x2)] x 2
[(6,3x3) +
(6,8x3)] x 2
[(6,3x3) + (6,3x3)] x 2
12 12 16 16 16
12 12 16 16 16
mm 800
m
3
/h 261 600 261 600 348 800 348 800 348 800
kW 19,2 19,2 25,6 25,6 25,6
m
3
/h 120,9 133,3 147,8 168,6 182,7
275 290 300 335 345
kPa
57,0 51,3 56,0 66,0 71,0
600 600 600 600 600
8"
400V / III / 50 Hz
A
805,2 893,3 939,0 1027,1 1197,6
554,5 642,6 688,3 776,4 863,4
NAC
410AR
Application Guide / NEOSYS-AGU-1801-E
Cooling mode
Cooling capacity
(1)
Power input
(1)
Seasonal Energy Effi ciency Ratio
(3)
SEER
Seasonal energy efficiency
(4)
ɳs,c
Seasonal Energy Performance Ratio
(5)
SEPR - High temperature (7°C)
Seasonal Energy Performance Ratio
(6)
SEPR - Medium temperature (-8°C)
Refrigeration circuit
Number of circuit
Refrigerant load per circuit (R410A)
Type of expansion valve Thermostatic expansion valve
Electronic expan-
sion valve
Compressors
Number of compressors
Type of compressor Scroll - Hermetic
Capacity steps
Oil type MOBIL EAL Arctic 22CC or ICI EMKARATE RL32CF
Oil load per compressor l
Condenser Microchannel aluminium tube and fi ns
Number of condenser
Fan & Motor Variable speed fans
Number of fans
Diameter
Maximum speed Variable speed - 900 rpm maximum
Nominal air fl ow (100%)
Total motor power input (900 rpm)
Evaporator AISI 304 stainless steel plate brazed with copper heat exchanger
Water fl ow rate
(1)
Water volume l
Pressure drop
(1)
Water operating pressure
Hydraulic connections Victaulic
Water inlet/outlet
Electrical data
Start-up intensity
Maximum current
GENERAL DATA
(1) EUROVENT certifi ed data, in accordance
with standard EN14511 :
Water inlet/outlet temperature = 12°C / 7°C
Outdoor air temperature = 35°C.
(2) ESEER following Eurovent calculation
method, in accordance with standard
EN14511
(3) SEER in accordance with standard
EN14825.
(4) Following ecodesign regulation nr
EU 2016/2281 on space cooling,
normalized leaving water temperature
at 7°C, in accordance with standard
EN14825.
(5) Following ecodesign regulation nr
EU 2016/2281 on process cooling units,
normalized leaving water temperature
at 7°C, in accordance with standard
EN14825.
(6) Following ecodesign regulation nr
EU 2015/1095 on process cooling chillers,
normalized leaving water temperature
at -8°C, in accordance with standard
EN14825.
