Optional Accessories for use with Communicating System
NOTE: 24V UV LIGHT
APPLICATIONS
In a communicating system, neither
furnace nor air handler
UV light applications. An additional
transformer for UV light applications
is required.
COMMUNICATING
THERMOSTAT
for even heat)
NOTE: COMMUNICATING THERMOSTAT SENSES HUMIDITY
& CONTROLS HUM CONTACTS TO CYCLE HUMIDIFIER
BASED ON DEMAND. NO OTHER CONTROL OR HUMIDISTAT
REQUIRED.
OPTIONAL OUTDOOR AIR SENSOR FOR USE WITH HUMIDI−
FIER (IF NOT ALREADY IN THE SYSTEM FOR OTHER FUNC−
TIONS. BUILT INTO ALL COMMUNICATING ENABLED OUT−
DOOR UNITS).
Maximum total
length of all con−
nections on the
RSBus is limited
to 1500ft.
Wire gauge of
RSBus wire is 18.
RSBus
Rf WGhGsCf
HVAC EQUIP
DEHUMIDIFIER
CONTROL
HVAC
EQUIPMENT
DH
*24V IN
JUMPER
COMMUNICATING
ENABLED FURNACE
COMMUNICATING
ENABLED FURNACE
COMMUNICATING
THERMOSTAT
CONVENTIONAL
NON−COMMUNI−
CATING SYSTEM
COMMUNICATING SYSTEM
CS 7000
THERMOSTAT
*24V IN jumper not used in non−
communicating configuration
24V HUMIDIFIER CONNECTIONS
120V CONNECTIONS
HEPA BYPASS FILTER X2680 HEPA INTERLOCK KIT
PASS INDOOR BLOWER
MOTOR COMMON WIRE
THROUGH CURRENT LOOP.
SEE HEPA INTERLOCK KIT
FOR INSTALLATION DE−
TAILS
LVCS VENTILATION CONTROL SYSTEM
SEE LVCS VENTILATION
INSTRUCTIONS FOR
DAMPER & SENSOR WIRING
“HUM” CONTACT IS
CLOSED ANYTIME
HUMIDITY DEMAND
IS PRESENT
COMMUNICATING
ENABLED FURNACE
COMMUNICATING
ENABLED FURNACE
A2L
H
