Lennox SL280DF090V48B

Page 7
PARTS IDENTIFICATION
BLOWER ASSEMBLY
INTERNAL FLUE
PIPE ASSEMBLY
FLUE CHASE
GASKET
DOOR INTERLOCK SWITCH
HEAT EXCHANGER
COMBUSTION AIR INDUCER
COMBUSTION AIR INDUCER
PRESSURE SWITCHES
GAS VALVE
BURNER BOX ASSEMBLY
INNER BLOWER ACCESS PANEL
ACCESS PANEL
CONTROL BOX
(Includes two-stage integrated control,
transformer and circuit breaker)
ROLLOUT SWITCH
PRIMARY LIMIT LOCATION
SECONDARY LIMIT
FIGURE 1
