Page 28
SL280UHNV HEATING COMPONENTS
FIGURE 13
Air Gas Plenum
Burner
Gasket
Orifice Housing
Gas Valve
Air Orifice
Sensor
Ignitor
Gas Orifice
Thermal
Switch
(location)
Intake Air Screen
Intake Air
Elbow
Coupling
O Ring
