Heat Exchanger and Burner Removal
FIGURE 24
Gas Valve
Air Intake Assembly
*Air Fuel Plenum
Air Fuel Plenum
Burner
Heat Exchanger
* Re−install screws per the numbered sequence shown
Gasket
Gasket
Gasket
(replace)
FIGURE 25
Remove 5 screws if necessary
(either side of cabinet)
1
2
3
4
5
