Page 28
HEATING COMPONENTS
Air Gas Plenum
Burner
Gasket
Orifice Housing
Gas Valve
Air Orifice
Sensor
Ignitor
Gas Orifice
Thermal
Switch
(location)
Intake Air Screen
Intake Air
Elbow
FIGURE 13
