Lennox SL280V User Manual

Page 35
BLOWER DATA
SL280DF070V36A BLOWER PERFORMANCE (less lter)
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1065 1170
+18% 1010 1115
+12% 960 1055
+6% 910 1000
Factory Default 860 945
–6% 805 885
–12% 755 830
–18% 705 775
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 745 870 1025 1075 1100 1240 1425 1515
Factory Default 665 780 925 985 1015 1115 1305 1380
– 590 690 815 865 900 1025 1170 1250
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch
Settings.
2
Factory default setting.
NOTES - The effect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28%, 38%, 70% and 100% of the selected second stage cooling speed - minimum 500 cfm.
Lennox Harmony III™ Zone Control Applications - Minimum blower speed is 425 cfm.
SL280DF090V48B BLOWER PERFORMANCE (less lter)
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1360 1500
+18% 1285 1415
+12% 1220 1350
+6% 1135 1285
Factory Default 1075 1200
–6% 1030 1110
–12% 960 1050
–18% 890 975
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 740 905 1040 1220 1085 1330 1545 1730
Factory Default 690 820 950 1110 990 1200 1400 1,595
– 610 745 855 1005 895 1075 1270 1460
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch
Settings.
2
Factory default setting.
NOTES - The effect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28%, 38%, 70% and 100% of the selected second stage cooling speed - minimum 500 cfm.
Lennox Harmony III™ Zone Control Applications - Minimum blower speed is 455 cfm.

Lennox SL280V Specifications

General

Efficiency	80% AFUE
Blower Type	Variable Speed
Energy Star Certified	No
Fuel Type	Natural Gas
Vent Type	Conventional
Heating Capacity	44, 000 to 132, 000 BTUH
Warranty	Limited lifetime heat exchanger warranty, 5-year parts warranty
