BLOWER DATA
SLP98UH070V36B BLOWER PERFORMANCE (less lter)
RIGHT SIDE RETURN AIR WITH OPTIONAL RETURN AIR BASE
HEATING BLOWER PERFORMANCE
Heating Adjust CFM Selections
Heating Input Range and Blower Volume - CFM
35% 40% 50% 60% 70% 80% 90% 100%
Increase (+15%) Heat CFM 471 519 614 709 805 900 996 1091
Increase (+7.5%) Heat CFM 435 480 570 660 751 841 931 1021
Default Heat CFM 399 441 526 611 696 781 866 951
Decrease (-7.5% ) Heat CFM 369 408 486 564 643 721 799 877
Decrease (-15% ) Heat CFM 339 375 446 517 589 660 732 803
COOLING BLOWER PERFORMANCE
Cooling Adjust CFM
Selections
Blower Speed Selections
First Stage Cool Speed - cfm Second Stage Cool Speed - cfm
Low Medium-
Low
Medium
High
High
(Default)
Low Medium-
Low
Medium
High
High
(Default)
Increase (+10%) Cool CFM 595 715 815 950 855 1045 1205 1350
Default Cool CFM 520 655 755 840 790 945 1090 1255
Decrease (-10%) Cool CFM 490 595 670 745 720 845 985 1130
The effect of static pressure is included in air volumes shown.
The following control congurations are available. See Installation Instructions for details and DIP switch settings.
Heat Modes Available (Heating Blower Performance Table):
Single stage thermostat:
- 35%, 70%, 100% input (three-stage) with time delays in-between
Two-stage thermostat:
- Variable Rate Capacity Mode - furnace automatically adjusts ring rate based on rst- and second-stage cycle times
- W1 demand at 70% input, W2 demand at 100% input. No delay between stages
icomfort Touch™ Communicating Thermostat:
- Variable Rate Capacity Mode - furnace automatically adjusts ring rate based on rst- and second-stage cycle times
- 35%, 60%, 80%, 100% (four-stage) with time delays in-between
Cool Mode Available (Cooling Blower Performance table):
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan speeds are approximately 28%, 38%, 70% and 100% (DIP switch selectable) of the same second-stage COOL speed position
minimum 300 cfm.
Lennox Harmony III™ Zoning System Applications - Minimum blower speed is 250 cfm.
SLP98UH090V36C BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
HEATING BLOWER PERFORMANCE
Heating Adjust CFM Selections
Heating Input Range and Blower Volume - CFM
35% 40% 50% 60% 70% 80% 90% 100%
Increase (+15%) Heat CFM 687 734 827 921 1014 1108 1201 1295
Increase (+7.5%) Heat CFM 654 697 782 867 953 1038 1123 1209
Default Heat CFM 621 660 737 814 891 968 1045 1122
Decrease (-7.5% ) Heat CFM 581 616 687 757 828 899 970 1041
Decrease (-15% ) Heat CFM 540 572 637 701 766 830 895 959
COOLING BLOWER PERFORMANCE
Cooling Adjust CFM
Selections
Blower Speed Selections
First Stage Cool Speed - cfm Second Stage Cool Speed - cfm
Low Medium-
Low
Medium
High
High
(Default)
Low Medium-
Low
Medium
High
High
(Default)
Increase (+10%) Cool CFM 625 710 830 950 875 1040 1210 1360
Default Cool CFM 565 670 760 860 800 945 1100 1240
Decrease (-10%) Cool CFM 520 610 685 785 720 840 970 1115
