Page 58
Field Installed
Gas Valve
MANIFOLD PRESSURE MEASUREMENT
FIGURE 49
Negative Port
Positive Port
Gas Valve
Measuring Device
Field Installed
Operating Signal (Delta P) Measurement
Black Tubing +
Red and Black Tubing -
FIGURE 50
