BLOWER DATA
SLP99DF090XV48C BLOWER PERFORMANCE (less lter)
HEATING BLOWER PERFORMANCE - 0 through 0.8 in. w.g. External Static Pressure Range
Heating Adjust CFM Selections
Heating Input Range and Blower Volume - CFM
35% 40% 50% 60% 70% 80% 90% 100%
Increase (+15%) Heat CFM 723 790 925 1060 1195 1329 1464 1599
Increase (+7.5%) Heat CFM 690 752 878 1004 1129 1255 1381 1507
Default Heat CFM 656 714 831 948 1064 1181 1297 1414
Decrease (-7.5% ) Heat CFM 601 654 761 867 974 1081 1188 1295
Decrease (-15% ) Heat CFM 545 593 690 787 884 981 1078 1175
The e󰀨ect of static pressure is included in air volumes shown.
The following control congurations are available. See Installation Instructions for details and DIP switch settings.
Heat Modes Available (Heating Blower Performance Table):
Single-stage thermostat:
- 35%, 70%, 100% input (three-stage) with time delays in-between
Two-stage thermostat:
- Variable Rate Capacity Mode - furnace automatically adjusts ring rate based on rst- and second-stage cycle times.
- W1 demand at 70% input, W2 demand at 100% input. No delay between stages.
Cool Mode Available (Cooling Blower Performance Table):
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan speeds are approximately 28% and 38% (DIP switch selectable) of the same second-stage COOL speed position minimum 250 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 380 cfm.
COOLING BLOWER PERFORMANCE - 0 through 1.0 in. w.g. External Static Pressure Range
Cooling Adjust CFM
Selections
Blower Speed Selections
First Stage Cool Speed - cfm Second Stage Cool Speed - cfm
Low Medium-
Low
Medium
High
High
(Default)
Low Medium-
Low
Medium
High
High
(Default)
Increase (+10%) Cool CFM 775 940 1100 1255 1120 1340 1535 1745
Default Cool CFM 690 875 975 1135 1000 1220 1425 1625
Decrease (-10%) Cool CFM 635 755 915 1025 920 1100 1270 1470
SLP99DF090XV48C BLOWER MOTOR WATTS - COOLING
Blower Speed
Options
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Increase (+10%) Cool CFM
Low 34 62 76 98 125 146 175 197 213 83 118 153 178 210 243 273 320 347 380 408
Medium-Low 52 80 102 134 167 188 211 242 267 132 162 217 252 316 339 384 435 465 502 541
Medium-High 70 106 135 174 200 235 268 309 336 242 279 329 376 426 464 497 547 601 643 673
High 105 147 182 218 267 303 341 395 412 350 397 443 515 559 619 681 739 770 813 869
Default Cool CFM
Low 30 51 67 92 107 131 145 165 192 55 83 114 147 181 204 241 261 290 324 360
Medium-Low 39 67 89 115 139 170 194 224 242 99 142 166 212 243 289 333 367 399 432 473
Medium-High 61 91 116 142 176 198 219 261 283 174 193 264 304 350 387 434 478 517 549 575
High 79 112 154 179 221 247 292 326 354 265 312 357 411 439 516 540 596 649 685 730
Decrease (-10%) Cool CFM
Low 25 43 58 80 100 113 136 152 166 48 72 101 123 151 181 198 229 256 283 300
Medium-Low 36 59 82 102 123 142 173 196 210 73 106 144 172 204 234 268 311 345 370 405
Medium-High 41 68 90 117 149 178 199 225 247 105 146 172 217 262 308 353 388 417 459 487
High 61 93 118 150 181 205 239 266 302 204 228 276 331 391 422 458 492 530 566 609
