BLOWER DATA
SLP99DF090XV60C BLOWER PERFORMANCE (less lter)
HEATING BLOWER PERFORMANCE - 0 through 0.8 in. w.g. External Static Pressure Range
Heating Adjust CFM Selections
Heating Input Range and Blower Volume - CFM
35% 40% 50% 60% 70% 80% 90% 100%
Increase (+15%) Heat CFM 653 728 877 1027 1176 1326 1475 1625
Increase (+7.5%) Heat CFM 603 673 813 953 1092 1232 1372 1512
Default Heat CFM 553 618 748 878 1009 1139 1269 1399
Decrease (-7.5% ) Heat CFM 510 570 690 811 931 1051 1171 1292
Decrease (-15% ) Heat CFM 467 522 632 743 853 963 1074 1184
The e󰀨ect of static pressure is included in air volumes shown.
The following control congurations are available. See Installation Instructions for details and DIP switch settings.
Heat Modes Available (Heating Blower Performance Table):
Single-stage thermostat:
- 35%, 70%, 100% input (three-stage) with time delays in-between
Two-stage thermostat:
- Variable Rate Capacity Mode - furnace automatically adjusts ring rate based on rst- and second-stage cycle times.
- W1 demand at 70% input, W2 demand at 100% input. No delay between stages.
Cool Mode Available (Cooling Blower Performance Table):
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan speeds are approximately 28% and 38% (DIP switch selectable) of the same second-stage COOL speed position minimum 250 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 450 cfm.
COOLING BLOWER PERFORMANCE - 0 through 1.0 in. w.g. External Static Pressure Range
Cooling Adjust CFM
Selections
Blower Speed Selections
First Stage Cool Speed - cfm Second Stage Cool Speed - cfm
Low Medium-
Low
Medium
High
High
(Default)
Low Medium-
Low
Medium
High
High
(Default)
Increase (+10%) Cool CFM 1110 1265 1395 1600 1600 1750 1965 2130
Default Cool CFM 1000 1145 1275 1445 1445 1625 1805 1975
Decrease (-10%) Cool CFM 885 1060 1145 1265 1265 1445 1645 1805
SLP99DF090XV60C BLOWER MOTOR WATTS - COOLING
Blower Speed
Options
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Increase (+10%) Cool CFM
Low 79 108 144 162 207 242 262 293 323 275 299 366 399 449 483 532 584 605 644 680
Medium-Low 120 156 187 233 261 279 329 368 401 387 409 471 521 562 606 650 688 716 762 800
Medium-High 155 202 235 293 317 369 407 453 502 547 577 622 667 744 795 835 872 910 950 963
High 268 299 366 399 449 483 532 584 605 780 775 811 898 942 994 1048 1071 1082 1080 1073
Default Cool CFM
Low 56 86 111 140 170 200 232 259 282 186 219 270 308 361 390 431 489 517 555 590
Medium-Low 93 118 152 195 223 254 283 306 344 278 304 365 420 450 510 544 592 640 665 698
Medium-High 123 161 201 228 260 310 341 381 416 446 475 528 582 616 662 686 747 780 823 855
High 182 219 270 308 361 390 431 489 517 576 603 654 704 756 809 871 902 939 972 975
Decrease (-10%) Cool CFM
Low 48 69 101 120 152 175 201 218 249 118 155 181 232 259 299 340 376 402 438 476
Medium-Low 65 94 123 150 185 220 250 278 296 177 205 267 304 353 390 430 486 515 563 587
Medium-High 93 118 152 195 223 254 283 306 344 301 322 392 439 468 531 568 599 647 678 721
High 116 155 181 232 259 299 340 376 402 446 475 528 582 616 662 686 747 780 823 855
