BLOWER DATA
SLP99DF110XV60C BLOWER PERFORMANCE (less lter)
HEATING BLOWER PERFORMANCE - 0 through 0.8 in. w.g. External Static Pressure Range
Heating Adjust CFM Selections
Heating Input Range and Blower Volume - CFM
35% 40% 50% 60% 70% 80% 90% 100%
Increase (+15%) Heat CFM 811 906 1096 1286 1475 1665 1855 2045
Increase (+7.5%) Heat CFM 744 835 1017 1199 1380 1562 1744 1926
Default Heat CFM 677 764 938 1112 1285 1459 1633 1807
Decrease (-7.5% ) Heat CFM 626 707 869 1031 1193 1355 1517 1679
Decrease (-15% ) Heat CFM 575 650 800 950 1101 1251 1401 1551
The e󰀨ect of static pressure is included in air volumes shown.
The following control congurations are available. See Installation Instructions for details and DIP switch settings.
Heat Modes Available (Heating Blower Performance Table):
Single-stage thermostat:
- 35%, 70%, 100% input (three-stage) with time delays in-between
Two-stage thermostat:
- Variable Rate Capacity Mode - furnace automatically adjusts ring rate based on rst- and second-stage cycle times.
- W1 demand at 70% input, W2 demand at 100% input. No delay between stages.
Cool Mode Available (Cooling Blower Performance Table):
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan speeds are approximately 28% and 38% (DIP switch selectable) of the same second-stage COOL speed position minimum 250 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 450 cfm.
COOLING BLOWER PERFORMANCE - 0 through 1.0 in. w.g. External Static Pressure Range
Cooling Adjust CFM
Selections
Blower Speed Selections
First Stage Cool Speed - cfm Second Stage Cool Speed - cfm
Low Medium-
Low
Medium
High
High
(Default)
Low Medium-
Low
Medium
High
High
(Default)
Increase (+10%) Cool CFM 1090 1260 1395 1580 1580 1790 1990 2180
Default Cool CFM 965 1125 1285 1440 1440 1625 1845 2000
Decrease (-10%) Cool CFM 860 1030 1125 1270 1270 1470 1655 1845
SLP99DF110XV60C BLOWER MOTOR WATTS - COOLING
Blower Speed
Options
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Increase (+10%) Cool CFM
Low 71 99 147 166 202 240 271 302 337 248 280 333 374 429 469 511 548 594 619 677
Medium-Low 127 159 198 225 256 301 325 365 390 409 427 496 531 587 632 665 721 742 781 805
Medium-High 162 204 242 287 316 371 408 446 487 563 589 651 703 755 808 860 888 932 970 1007
High 243 280 333 374 429 469 511 548 594 866 850 915 963 1020 1056 1091 1127 1141 1136 1131
Default Cool CFM
Low 57 88 117 140 165 196 232 259 283 167 214 244 291 331 380 405 467 497 539 583
Medium-Low 77 112 147 172 209 250 283 317 345 275 321 348 418 447 505 546 597 632 668 716
Medium-High 122 154 199 230 268 300 331 373 411 461 493 547 572 628 666 703 745 777 819 860
High 167 214 244 291 331 380 405 467 497 601 626 688 730 787 823 880 924 963 994 1011
Decrease (-10%) Cool CFM
Low 44 67 99 115 144 167 197 215 245 126 165 201 232 262 305 334 373 417 451 479
Medium-Low 66 97 123 153 186 216 247 275 303 187 219 272 308 360 391 432 479 514 559 588
Medium-High 77 112 147 172 209 250 283 317 345 308 341 390 430 490 528 569 617 640 691 724
High 127 165 201 232 262 305 334 373 417 461 493 547 572 628 666 703 745 777 819 860
