INDOOR PIPE SELECTION (L2, A, B, C, D, E, F, G, H)
Indoor Unit Type Indoor Unit Size Gas Pipe Diameter Liquid Pipe Diameter
V22B Compact 360° Cassette 007, 009, 012, 015 1/2 in. 1/4 in.
V33B High E󰀩ciency 360° Cassette
009, 012, 015 1/2 in. 1/4 in.
018, 024, 030,
036, 048
5/8 in. 3/8 in.
VOWA One-Way Cassette
007, 009, 012, 015 1/2 in. 1/4 in.
018, 024 5/8 in. 3/8 in.
VCFB Ceiling/Floor Mount Non-Ducted
012, 015 1/2 in. 1/4 in.
018, 024, 030,
036, 048
5/8 in. 3/8 in.
VHIB Concealed High Static Ducted
012, 015 1/2 1/4
024, 030, 036,
048, 054
5/8 in. 3/8 in.
072 7/8 in. 3/8 in.
VOSB Outside Air Unit
036, 048, 054, 072 5/8 in. 3/8 in.
072 7/8 in. 3/8 in.
VMDB Concealed Medium Static Ducted
007, 009, 012, 015 1/2 in. 1/4 in.
018, 024, 030,
036, 048
5/8 in. 3/8 in.
VVCB Vertical Air Handler
012 1/2 in. 1/4 in.
018, 024, 030,
036, 048, 054
5/8 in. 3/8 in.
060 7/8 in. 3/8 in.
VWMB Wall-Mounted Non-Ducted
007, 009, 012, 015 1/2 in. 1/4 in.
018, 024, 030 5/8 in. 3/8 in.
NOTES:
If the total capacity of the indoor units is greater than 100% of the capacity of the outdoor unit, individual indoor unit capacities will be reduced.
