Lennox XC14 User Manual

XC14 - 1.5 to 5 Ton Air Conditioner / Page 29
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Expansion
Device
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC14-042-230 TXV 39,500 14.20 12.00 C33-36 SL280UH090XV60C 4235562
XC14-042-230 TXV 39,500 14.20 12.00 C33-36 SL280UH110V60C 4035305
XC14-042-230 TXV 39,500 14.20 12.00 C33-36 SL280UH110XV60C 4040441
XC14-042-230 TXV 39,000 13.50 11.50 C33-36 SLP98UH070V36B 4020456
XC14-042-230 TXV 39,000 13.70 11.70 C33-36 SLP98UH090V36C 4020457
XC14-042-230 TXV 39,500 14.00 12.00 C33-36 SLP98UH090V48C 4020458
XC14-042-230 TXV 39,500 14.00 11.70 C33-36 SLP98UH090V60C 4020459
XC14-042-230 TXV 39,500 14.00 12.00 C33-36 SLP98UH110V60C 4020460
XC14-042-230 TXV 39,000 13.00 11.20 C33-36 1235329
XC14-042-230 TXV 39,500 13.70 11.70 C33-38 G61MPV-36B-070 1235349
XC14-042-230 TXV 39,500 13.70 11.70 C33-38 G61MPV-36B-071 1248129
XC14-042-230 TXV 41,000 14.50 12.20 C33-38 SL280UH090V36B 4035306
XC14-042-230 TXV 41,000 14.70 12.50 C33-38 SL280UH090V48B 4035307
XC14-042-230 TXV 41,000 14.70 12.50 C33-38 SL280UH090XV48B 4038651
XC14-042-230 TXV 40,500 14.00 12.00 C33-38 SLP98UH070V36B 4020461
XC14-042-230 TXV 40,000 13.50 11.50 C33-38 1235330
XC14-042-230 TXV 40,000 13.50 11.50 C33-38B 3293436
XC14-042-230 TXV 38,500 13.50 11.50 C33-42 G61MPV-36B-070 1235351
XC14-042-230 TXV 38,500 13.50 11.50 C33-42 G61MPV-36B-071 1248130
XC14-042-230 TXV 39,000 14.00 11.70 C33-42 SL280UH090V36B 4035308
XC14-042-230 TXV 39,000 14.00 12.00 C33-42 SL280UH090V48B 4035309
XC14-042-230 TXV 39,000 14.00 12.00 C33-42 SL280UH090XV48B 4038652
XC14-042-230 TXV 39,000 13.50 11.50 C33-42 SLP98UH070V36B 4020462
XC14-042-230 TXV 39,000 13.00 11.20 C33-42 1235331
XC14-042-230 TXV 40,500 14.20 12.00 C33-43 G61MPV-36B-070 1235353
XC14-042-230 TXV 40,500 14.20 12.00 C33-43 G61MPV-36B-071 1248131
XC14-042-230 TXV 41,500 14.70 12.70 C33-43 G61MPV-60C-090 1235356
XC14-042-230 TXV 41,500 14.50 12.50 C33-43 G61MPV-60C-091 1235358
XC14-042-230 TXV 41,500 15.00 12.70 C33-43 G61MPV-60C-110 1235357
XC14-042-230 TXV 41,500 14.70 12.70 C33-43 G61MPV-60C-111 1235359
XC14-042-230 TXV 41,000 14.50 12.20 C33-43 SL280UH090V36B 4035310
XC14-042-230 TXV 41,000 14.70 12.50 C33-43 SL280UH090V48B 4035311
XC14-042-230 TXV 41,500 15.20 12.70 C33-43 SL280UH090V60C 4035312
XC14-042-230 TXV 41,000 14.70 12.50 C33-43 SL280UH090XV48B 4038653
XC14-042-230 TXV 41,500 15.20 12.70 C33-43 SL280UH090XV60C 4235563
XC14-042-230 TXV 41,500 15.00 12.70 C33-43 SL280UH110V60C 4035313
XC14-042-230 TXV 41,500 15.00 12.70 C33-43 SL280UH110XV60C 4040442
XC14-042-230 TXV 41,000 14.00 12.00 C33-43 SLP98UH070V36B 4020463
XC14-042-230 TXV 41,500 14.70 12.50 C33-43 SLP98UH090V36C 4020464
XC14-042-230 TXV 41,500 14.70 12.50 C33-43 SLP98UH090V48C 4020465
XC14-042-230 TXV 41,500 14.70 12.50 C33-43 SLP98UH090V60C 4020466
XC14-042-230 TXV 41,500 15.00 12.70 C33-43 SLP98UH110V60C 4020467
XC14-042-230 TXV 41,000 13.70 11.70 C33-43 1235332
XC14-042-230 TXV 40,500 14.50 12.20 C33-48 G61MPV-60C-090 1235362
XC14-042-230 TXV 41,000 14.20 12.20 C33-48 G61MPV-60C-091 1235364
XC14-042-230 TXV 40,500 14.50 12.20 C33-48 G61MPV-60C-110 1235363
XC14-042-230 TXV 40,500 14.50 12.20 C33-48 G61MPV-60C-111 1235365
XC14-042-230 TXV 40,500 14.20 12.20 C33-48 SL280UH090V36B 4035291
XC14-042-230 TXV 40,500 14.50 12.20 C33-48 SL280UH090V48B 4035292
XC14-042-230 TXV 41,000 14.50 12.50 C33-48 SL280UH090V60C 4035293
XC14-042-230 TXV 40,500 14.50 12.20 C33-48 SL280UH090XV48B 4038649
XC14-042-230 TXV 41,000 14.50 12.50 C33-48 SL280UH090XV60C 4235558
XC14-042-230 TXV 40,500 14.50 12.20 C33-48 SL280UH110V60C 4035294
XC14-042-230 TXV 40,500 14.50 12.20 C33-48 SL280UH110XV60C 4040437
XC14-042-230 TXV 40,000 13.70 11.70 C33-48 SLP98UH070V36B 4020468
XC14-042-230 TXV 40,500 14.20 12.20 C33-48 SLP98UH090V36C 4020469
XC14-042-230 TXV 40,500 14.50 12.20 C33-48 SLP98UH090V48C 4020470
XC14-042-230 TXV 41,000 14.20 12.20 C33-48 SLP98UH090V60C 4020471
NOTES:
TXV = Matched with Thermostatic Expansion Valve.
RFC = Matched with RFC metering device.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see Expansion Valve Kit Usage Table.

Lennox XC14 Specifications

General

Compressor Type	Single-Stage
Refrigerant	R-410A
Energy Star Certified	Yes
Cooling Capacity (BTU/h)	18, 000 to 60, 000
Cooling Capacity	1.5 - 5 tons
EER Rating	Up to 13.00
Warranty	10-year limited warranty on compressor, 5-year limited warranty on parts
SEER Rating	Up to 16.00
Compressor	Scroll
