Lennox XC14 User Manual

XC14 - 1.5 to 5 Ton Air Conditioner / Page 6
SPECIFICATIONS
General
Data
Model No. XC14-018 XC14-024 XC14-030 XC14-036
Nominal Tonnage 1.5 2 2.5 3
Connections
(sweat)
Liquid line (o.d.) - in. 3/8 3/8 3/8 3/8
Suction line (o.d.) - in. 3/4 3/4 3/4 7/8
Refrigerant
1
R-410A charge furnished 5 lbs. 11 oz. 6 lbs. 8 oz. 6 lbs. 11 oz. 6 lbs. 11 oz.
Outdoor
Coil
Net face area - sq. ft. 13.22 18.67 21.00 21.00
Tube diameter - in. 5/16 5/16 5/16 5/16
No. of rows 1 1 1 1
Fins per inch 26 26 26 26
Outdoor
Fan
Diameter - in. 18 22 22 22
No. of blades 3 3 3 3
Motor hp 1/10 1/6 1/6 1/6
Cfm 2270 3160 3160 3160
Rpm 1050 850 850 850
Watts 165 215 215 215
Shipping Data - lbs. 1 pkg. 163 203 215 217
ELECTRICAL DATA
Line voltage data - 60hz 208/230V-1ph 208/230V-1ph 208/230V-1ph 208/230V-1ph
2
Maximum overcurrent protection (amps) 25 30 30 30
3
Minimum circuit ampacity 15.7 17.9 17.2 18.7
Compressor Rated load amps 9.0 13.4 12.9 14.1
Locked rotor amps 48 58 64 77
Power factor 0.96 0.97 0.98 0.98
Outdoor Fan Motor Full load amps 0.7 1.1 1.1 1.1
Locked rotor amps 1.4 2.1 2.1 2.1
OPTIONAL ACCESSORIES - MUST BE ORDERED EXTRA
Compressor Hard Start Kit 88M91
   
Compressor Low Ambient Cut-Off 45F08
   
Compressor Time-Off Control 47J27
   
Freezestat 3/8 in. tubing 93G35
   
5/8 in. tubing 50A93
   
Low Ambient Kit 34M72
   
Refrigerant Line
Sets
L15-41-20 L15-41-40
L15-41-30 L15-41-50
   
Indoor Blower Off Delay Relay 58M81
   
NOTE - Extremes of operating range are plus 10% and minus 5% of line voltage.
1
Refrigerant charge sufcient for 15 ft. length of refrigerant lines.
2
HACR type breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
