CABINET
Heavy-gauge steel construction
Pre-painted cabinet nish.
Painted base section.
Control box is conveniently located with all controls
factory wired.
Corner patch plate allows access to compressor
components.
Drainage holes are provided in base section for
moisture removal.
High density polyethylene unit support feet raise the
unit off of the mounting surface, away from damaging
moisture.
SmartHinge™ Louvered Coil Protection
Steel louvered panels provides
complete coil protection.
Panels are hinged to allow easy
cleaning and servicing of coils.
Panels may be completely
removed.
Interlocking tabs and slots
assure tight t on cabinet.
Refrigerant Line Connections, Electrical Inlets and
Service Valves
Suction and liquid lines are located on corner of unit
cabinet and are made with sweat connections.
See dimension drawing.
Fully serviceable brass service valves prevent corrosion
and provide access to refrigerant system. Suction valve
can be fully shut off, while liquid valve may be front
seated to manage refrigerant charge while servicing
system.
Refrigerant line connections and eld wiring inlets are
located in one central area of the cabinet.
See dimension drawing.
