XC16 - 2 to 5 Ton Heat Pump / Page 19
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-048-230 + TXV 47,000 15.00 11.70 CH33-50/60C G61MPV-60C-111 1046663
XC16-048-230 + TXV 47,000 15.20 11.70 CH33-50/60C G71MPP-60C-090 3094648
XC16-048-230 + TXV 47,000 15.00 11.70 CH33-50/60C G71MPP-60C-110 1488409
XC16-048-230 + TXV 47,000 14.20 11.70 CH33-50/60C 1050279
XC16-048-230 + TXV 47,000 15.50 12.20 CH33-60D G60UHV-60D-135 1003994
XC16-048-230 + TXV 47,000 15.50 12.20 CH33-60D G61MPV-60D-135 1003993
XC16-048-230 + TXV 46,500 14.00 11.50 CH33-60D 1003992
XC16-048-230 + TXV 47,000 15.50 12.20 CH33-60D G71MPP-60D-135 1489284
XC16-048-230 + TXV 47,000 15.50 12.20 CH33-62D G60UHV-60D-135 1003757
XC16-048-230 + TXV 47,500 15.50 12.20 CH33-62D G61MPV-60D-135 1003758
XC16-048-230 + TXV 47,000 14.00 11.50 CH33-62D 1003725
XC16-048-230 + TXV 47,500 15.50 12.20 CH33-62D G71MPP-60D-135 1489277
XC16-048-230 + TXV 44,500 14.70 11.70 CR33-48 G60DFV-60C-090 1003756
XC16-048-230 + TXV 45,000 14.70 11.50 CR33-48 G60DFV-60C-110 1003755
XC16-048-230 + TXV 44,500 14.20 11.20 CR33-48 G61MPV-60C-110 1003754
XC16-048-230 + TXV 44,500 13.20 11.00 CR33-48 1003771
XC16-048-230 + TXV 44,500 14.20 11.20 CR33-48 G61MPV-60C-091 1046664
XC16-048-230 + TXV 44,500 14.20 11.20 CR33-48 G61MPV-60C-111 1046665
XC16-048-230 + TXV 44,500 14.20 11.20 CR33-48 G71MPP-60C-110 1488401
XC16-048-230 + TXV 47,000 15.20 12.20 CR33-50/60 G60DFV-60C-090 1003763
XC16-048-230 + TXV 46,500 15.20 12.00 CR33-50/60 G60DFV-60C-110 1003764
XC16-048-230 + TXV 46,000 15.20 11.70 CR33-50/60 G61MPV-60C-090 1003762
XC16-048-230 + TXV 46,000 13.70 11.20 CR33-50/60 1003770
XC16-048-230 + TXV 46,000 14.70 11.50 CR33-50/60 G61MPV-60C-091 1046666
XC16-048-230 + TXV 46,000 15.00 11.70 CR33-50/60 G61MPV-60C-111 1046667
XC16-048-230 + TXV 46,500 15.50 12.00 CR33-60 G60UHV-60D-135 1003760
XC16-048-230 + TXV 46,000 13.70 11.20 CR33-60 1005092
XC16-048-230 + TXV 46,000 15.00 11.70 CX34-44/48 G60UHV-60C-090 1003959
XC16-048-230 + TXV 45,500 15.00 11.70 CX34-44/48 G60UHV-60C-110 1003960
XC16-048-230 + TXV 45,500 14.70 11.50 CX34-44/48 G61MPV-60C-090 1003961
XC16-048-230 + TXV 45,500 14.70 11.70 CX34-44/48 CBWMV-60C-100 3060548
XC16-048-230 + TXV 45,500 14.70 11.20 CX34-44/48 G61MPV-60C-091 1046668
XC16-048-230 + TXV 45,500 14.50 11.50 CX34-44/48 G61MPV-60C-111 1046669
XC16-048-230 + TXV 45,500 14.70 11.50 CX34-44/48 G71MPP-60C-090 3145299
XC16-048-230 + TXV 45,500 13.70 11.20 CX34-44/48 3024355
XC16-048-230 + TXV 47,500 15.50 12.20 CX34-49 G60UHV-60C-090 1003911
XC16-048-230 + TXV 47,500 15.50 12.20 CX34-49 G60UHV-60C-110 1003912
XC16-048-230 + TXV 47,500 15.00 12.00 CX34-49 G61MPV-60C-110 1003910
XC16-048-230 + TXV 46,500 14.70 11.70 CX34-49 O23V5-140/154 1003909
XC16-048-230 + TXV 47,500 15.20 12.00 CX34-49 G61MPV-60C-090 3490811
XC16-048-230 + TXV 47,500 15.00 11.70 CX34-49 G61MPV-60C-091 1046670
XC16-048-230 + TXV 47,000 15.00 11.70 CX34-49 G61MPV-60C-111 1046671
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.

Lennox XC16 Specifications

General

SEER Rating	Up to 17.20
Cooling Capacity	1.5 to 5 tons
Sound Level	As low as 72 dB
Energy Star Certified	Yes
Refrigerant	R-410A
Warranty	10-Year Limited Warranty on compressor and parts
Compressor	Single-stage
