Lennox XC16 User Manual

XC16 - 2 to 5 Ton Heat Pump / Page 18
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-048-230 + TXV 47,000 15.70 12.20 CB27UH-048-230 1348995
XC16-048-230 + TXV 46,500 15.50 12.20 CB27UH-060-230 1348996
XC16-048-230 + TXV 47,000 14.70 12.00 CB30M-51P 1003794
XC16-048-230 + TXV 47,500 14.50 11.70 CB30M-65P 1003793
XC16-048-230 + TXV 48,000 14.70 11.70 CBX26UH-042 1003953
XC16-048-230 + TXV 48,000 14.70 12.00 CBX26UH-048 1003954
XC16-048-230 + TXV 47,000 15.70 12.20 CBX27UH-048-230 1145118
XC16-048-230 + TXV 46,500 15.50 12.20 CBX27UH-060-230 1145119
XC16-048-230 + TXV 47,000 14.70 12.00 CBX32M-048 1003958
XC16-048-230 + TXV 47,500 14.50 11.70 CBX32M-060 1003957
XC16-048-230 + TXV 47,000 15.70 12.20 CBX32MV-048 1003956
XC16-048-230 + TXV 47,500 15.70 12.20 CBX32MV-060 1003955
XC16-048-230 + TXV 47,500 15.70 12.50 CBX32MV-068 1003963
XC16-048-230 + TXV 47,000 15.70 12.20 CBX40UHV-048 3291798
XC16-048-230 + TXV 47,500 15.70 12.20 CBX40UHV-060 3291847
XC16-048-230 + TXV 45,000 15.20 11.70 CH23-51 G60UHV-60C-090 1038817
XC16-048-230 + TXV 45,000 13.50 11.20 CH23-51 1003722
XC16-048-230 + TXV 56,000 14.50 11.00 CH23-65 G60UHV-60C-090 1038818
XC16-048-230 + TXV 45,500 13.70 11.20 CH23-65 1003998
XC16-048-230 + TXV 47,000 14.20 11.70 CH23-68 1003723
XC16-048-230 + TXV 46,500 15.20 11.70 CH33-48 G60UHV-60C-090 1003971
XC16-048-230 + TXV 46,500 15.20 11.70 CH33-48 G60UHV-60C-110 1003973
XC16-048-230 + TXV 46,500 15.00 11.70 CH33-48 G61MPV-60C-090 1003972
XC16-048-230 + TXV 46,500 15.00 11.70 CH33-48 G61MPV-60C-091 1046660
XC16-048-230 + TXV 46,500 14.70 11.70 CH33-48 G61MPV-60C-111 1046661
XC16-048-230 + TXV 46,500 15.00 11.70 CH33-48 G71MPP-60C-090 3094645
XC16-048-230 + TXV 46,000 14.00 11.20 CH33-48C 1003724
XC16-048-230 + TXV 47,500 15.50 12.20 CH33-49 G60UHV-60C-090 1132856
XC16-048-230 + TXV 47,500 15.50 12.20 CH33-49 G60UHV-60C-110 1132857
XC16-048-230 + TXV 47,500 15.20 12.00 CH33-49 G61MPV-60C-090 1132858
XC16-048-230 + TXV 47,500 15.00 11.50 CH33-49 G61MPV-60C-091 1132859
XC16-048-230 + TXV 47,500 15.00 12.00 CH33-49 G61MPV-60C-110 1132860
XC16-048-230 + TXV 47,500 15.00 11.70 CH33-49 G61MPV-60C-111 1132861
XC16-048-230 + TXV 47,500 15.20 12.00 CH33-49 G71MPP-60C-090 3094646
XC16-048-230 + TXV 47,500 15.00 12.00 CH33-49 G71MPP-60C-110 1488548
XC16-048-230 + TXV 47,000 14.20 11.70 CH33-49 1132855
XC16-048-230 + TXV 47,500 15.50 12.20 CH33-50/60C G60UHV-60C-090 1003970
XC16-048-230 + TXV 47,000 15.20 12.00 CH33-50/60C G60UHV-60C-110 1003969
XC16-048-230 + TXV 47,000 15.00 11.70 CH33-50/60C G61MPV-60C-110 1003968
XC16-048-230 + TXV 47,000 15.50 12.00 CH33-50/60C CBWMV-60C-100 1088639
XC16-048-230 + TXV 47,000 15.20 11.70 CH33-50/60C G61MPV-60C-090 3094647
XC16-048-230 + TXV 47,000 15.20 11.70 CH33-50/60C G61MPV-60C-091 1046662
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.

Lennox XC16 Specifications

General

SEER Rating	Up to 17.20
Cooling Capacity	1.5 to 5 tons
Sound Level	As low as 72 dB
Energy Star Certified	Yes
Refrigerant	R-410A
Warranty	10-Year Limited Warranty on compressor and parts
Compressor	Single-stage
