XC16 - 2 to 5 Ton Heat Pump / Page 8
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-024-230 + TXV 25,200 15.70 12.70 C33-19 CBWMV-24B-040 3496089
XC16-024-230 + TXV 25,400 16.50 12.70 C33-19 G60UHV-36A-070 3069061
XC16-024-230 + TXV 24,800 14.20 11.50 C33-19 3069056
XC16-024-230 + TXV 25,800 16.50 13.00 C33-25 G60UHV-36A-070 3069062
XC16-024-230 + TXV 26,000 16.70 13.20 C33-25 G60UHV-36B-090 3069063
XC16-024-230 + TXV 26,000 16.50 13.00 C33-25 G61MPV-36B-045 3069064
XC16-024-230 + TXV 25,800 16.50 13.00 C33-25 G61MPV-36B-070 3069065
XC16-024-230 + TXV 25,800 16.50 13.00 C33-25 G71MPP-36B-070 3069066
XC16-024-230 + TXV 25,200 14.20 11.70 C33-25 3069057
XC16-024-230 + TXV 25,200 16.00 12.70 C33-30 G60UHV-36A-070 3069067
XC16-024-230 + TXV 25,200 16.00 12.70 C33-30 G60UHV-36B-090 3069068
XC16-024-230 + TXV 25,200 15.70 12.50 C33-30 G61MPV-36B-045 3069069
XC16-024-230 + TXV 25,200 15.70 12.70 C33-30 G61MPV-36B-070 3069070
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.
*tXV SUBSTITUTIONS
Indoor Coils/Air Handlers with factory installed expansion
valves that require eld replacement
Model No.
Indoor Coil or Air
Handler
Order No.
XC16-024 CBX26UH-024 37L51
XC16-036 CX34-42 37L51
XC16-036 CX34-43 37L51
XC16-036 CX34-44/48 37L51
XC16-036 CX34-49 37L51
XC16-036 CBX26UH-030 37L51
XC16-036 CBX27UH-072 37L51
XC16-036 CBX32M-042 37L51
XC16-036 CBX32MV-024/030 37L51
XC16-036 CBX32MV-048 37L51
XC16-036 CBX40UHV-030 37L51
XC16-036 CBX40UHV-042 37L51
XC16-036 CBX40UHV-048 37L51
XC16-048 CX34-44/48 91M02
XC16-048 CBX26UH-042 91M02
*CX34 coils and all air handlers (except CB26UH “R”) - the factory installed
expansion valve must be replaced with the expansion valve listed (ordered
separately). If the combination is not listed above, the factory installed TXV is
used.
C33 and CH33 coils and CB26UH “R” air handlers - use the RFC shipped with
the outdoor unit or replace the factory installed RFC with the expansion valve
listed in the Thermal Expansion Valves Table.
CR33 and CH23 - use the RFC shipped with the outdoor unit or use the expan-
sion valve listed in the Thermal Expansion Valves Table.
THERMAL EXPANSION VALVES (TXV)
Model No. Order No.
XC16-024 37L51
XC16-036 37L51
XC16-048 91M02
XC16-060 91M02
CX34 upow coils and all Lennox air handlers (except CB26UH “R”) are
shipped with a factory installed TXV. In most cases, no change out of the valve
is needed.
If a change out is required it will be listed in the “TXV SUBSTITUTIONS” table.
The correct TXV must be ordered and eld installed. C33 coils and all horizontal
and downow coils are shipped without a TXV. The TXV must be ordered and
eld installed.
MOST POPULAR MATCHES
Outdoor Unit
Model No.
Indoor Unit
Model No
XC16-024 CX34-36B with G60UHV-36B-040
XC16-036 CX34-43C with G60UHV-60C-110
XC16-048 CX34-62C with G60UHV-60C-090
XC16-060 CX34-62C with G60UHV-60C-090
