Lennox XC16 User Manual

XC16 - 2 to 5 Ton Heat Pump / Page 9
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-024-230 + TXV 25,200 16.00 12.50 C33-30 G61MPV-36B-071 3069072
XC16-024-230 + TXV 25,000 16.00 12.70 C33-30 G61MPV-36C-090 3069163
XC16-024-230 + TXV 25,200 15.70 12.70 C33-30 G71MPP-36B-070 3069071
XC16-024-230 + TXV 25,000 16.00 12.70 C33-30 G71MPP-36C-090 3069164
XC16-024-230 + TXV 26,200 16.70 13.20 C33-31 G60UHV-36A-070 3069073
XC16-024-230 + TXV 26,400 17.00 13.50 C33-31 G60UHV-36B-090 3069074
XC16-024-230 + TXV 26,400 16.70 13.20 C33-31 G61MPV-36B-045 3069075
XC16-024-230 + TXV 26,200 16.70 13.20 C33-31 G61MPV-36B-070 3069076
XC16-024-230 + TXV 26,400 16.70 13.20 C33-31 G61MPV-36B-071 3069078
XC16-024-230 + TXV 26,200 16.70 13.20 C33-31 G71MPP-36B-070 3069077
XC16-024-230 + TXV 25,600 14.50 12.00 C33-31 3069058
XC16-024-230 + TXV 25,200 15.50 12.70 C33-36 CBWMV-24B-040 3493246
XC16-024-230 + TXV 25,800 16.50 13.00 C33-36 G60UHV-36A-070 3069079
XC16-024-230 + TXV 25,400 16.00 12.70 C33-36 G60UHV-36B-090 3068760
XC16-024-230 + TXV 25,800 16.50 13.00 C33-36 G61MPV-36B-045 3069080
XC16-024-230 + TXV 25,800 16.50 13.00 C33-36 G61MPV-36B-070 3069081
XC16-024-230 + TXV 25,800 16.50 13.00 C33-36 G61MPV-36B-071 3069083
XC16-024-230 + TXV 25,600 16.50 13.20 C33-36 G61MPV-36C-090 3069084
XC16-024-230 + TXV 25,800 16.50 13.00 C33-36 G71MPP-36B-070 3069082
XC16-024-230 + TXV 25,600 16.50 13.20 C33-36 G71MPP-36C-090 3069085
XC16-024-230 + TXV 24,600 13.70 11.50 C33-36 3069059
XC16-024-230 + TXV 26,400 17.00 13.20 C33-38 G60UHV-36A-070 3069086
XC16-024-230 + TXV 26,600 17.00 13.50 C33-38 G60UHV-36B-090 3069087
XC16-024-230 + TXV 26,600 16.70 13.20 C33-38 G61MPV-36B-045 3069088
XC16-024-230 + TXV 26,400 17.00 13.20 C33-38 G61MPV-36B-070 3069089
XC16-024-230 + TXV 26,600 17.00 13.20 C33-38 G61MPV-36B-071 3069091
XC16-024-230 + TXV 26,400 17.00 13.20 C33-38 G71MPP-36B-070 3069090
XC16-024-230 + TXV 25,400 14.20 11.70 C33-38 3069060
XC16-024-230 + TXV 26,000 15.20 12.50 CB26UH-024 3069092
XC16-024-230 + TXV 26,000 16.20 13.20 CB27UH-024-230 3069094
XC16-024-230 + TXV 26,200 17.00 13.50 CB27UH-030-230 3069095
XC16-024-230 + TXV 25,400 14.50 12.00 CB30M-21/26P 3069093
XC16-024-230 + TXV 26,000 15.20 12.50 CBX26UH-024 3068837
XC16-024-230 + TXV 26,000 16.20 13.20 CBX27UH-024-230 3068841
XC16-024-230 + TXV 26,200 17.00 13.50 CBX27UH-030-230 3068842
XC16-024-230 + TXV 25,400 14.50 12.00 CBX32M-018/024 3068838
XC16-024-230 + TXV 25,400 15.50 12.20 CBX32MV-018/024 3068839
XC16-024-230 + TXV 25,600 15.50 12.50 CBX32MV-024/030 3068840
XC16-024-230 + TXV 25,400 15.50 12.20 CBX40UHV-024 3291609
XC16-024-230 + TXV 25,600 15.50 12.50 CBX40UHV-030 3291634
XC16-024-230 + TXV 24,600 16.00 12.70 CH23-31 G61MPV-36B-070 3068814
XC16-024-230 + TXV 24,600 16.00 12.70 CH23-31 G71MPP-36B-070 3068815
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.

Lennox XC16 Specifications

General

SEER Rating	Up to 17.20
Cooling Capacity	1.5 to 5 tons
Sound Level	As low as 72 dB
Energy Star Certified	Yes
Refrigerant	R-410A
Warranty	10-Year Limited Warranty on compressor and parts
Compressor	Single-stage
