XC16 - 2 to 5 Ton Heat Pump / Page 10
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-024-230 + TXV 24,000 13.50 11.00 CH23-31 3068767
XC16-024-230 + TXV 25,800 16.50 13.00 CH23-41 G60UHV-36A-070 3068816
XC16-024-230 + TXV 25,200 14.20 11.70 CH23-41 3068768
XC16-024-230 + TXV 25,400 16.20 12.70 CH33-19 G60UHV-36A-070 3068817
XC16-024-230 + TXV 24,800 14.00 11.50 CH33-19 3068769
XC16-024-230 + TXV 25,200 16.00 12.70 CH33-24/30 G60UHV-36A-070 3068818
XC16-024-230 + TXV 24,600 14.00 11.50 CH33-24/30 3068843
XC16-024-230 + TXV 26,000 16.50 13.00 CH33-25A G60UHV-36A-070 3068819
XC16-024-230 + TXV 25,400 14.50 11.70 CH33-25A 3068772
XC16-024-230 + TXV 25,800 16.70 13.20 CH33-25B G60UHV-36B-090 3068820
XC16-024-230 + TXV 25,800 16.50 13.00 CH33-25B G61MPV-36B-045 3068821
XC16-024-230 + TXV 25,800 16.50 13.00 CH33-25B G61MPV-36B-070 3068822
XC16-024-230 + TXV 26,000 16.50 13.00 CH33-25B G61MPV-36B-071 3068824
XC16-024-230 + TXV 25,800 16.50 13.00 CH33-25B G71MPP-36B-070 3068823
XC16-024-230 + TXV 25,200 14.20 11.70 CH33-25B 3068773
XC16-024-230 + TXV 26,400 16.70 13.20 CH33-31A G60UHV-36A-070 3068825
XC16-024-230 + TXV 25,800 14.70 12.00 CH33-31A 3068774
XC16-024-230 + TXV 26,600 17.00 13.50 CH33-31B G60UHV-36B-090 3068826
XC16-024-230 + TXV 26,400 16.70 13.20 CH33-31B G61MPV-36B-045 3068827
XC16-024-230 + TXV 26,400 16.70 13.20 CH33-31B G61MPV-36B-070 3068828
XC16-024-230 + TXV 26,600 17.00 13.20 CH33-31B G61MPV-36B-071 3068830
XC16-024-230 + TXV 26,400 16.70 13.20 CH33-31B G71MPP-36B-070 3068829
XC16-024-230 + TXV 25,800 14.50 12.00 CH33-31B 3068775
XC16-024-230 + TXV 25,600 16.20 12.70 CH33-36A G60UHV-36A-070 3068831
XC16-024-230 + TXV 25,200 14.20 11.70 CH33-36A 3068770
XC16-024-230 + TXV 25,800 16.70 13.20 CH33-36B G60UHV-36B-090 3068832
XC16-024-230 + TXV 25,800 16.20 13.00 CH33-36B G61MPV-36B-045 3068833
XC16-024-230 + TXV 25,800 16.50 13.00 CH33-36B G61MPV-36B-070 3068834
XC16-024-230 + TXV 25,800 16.50 13.00 CH33-36B G61MPV-36B-071 3068836
XC16-024-230 + TXV 25,800 16.50 13.00 CH33-36B G71MPP-36B-070 3068835
XC16-024-230 + TXV 25,000 14.20 11.70 CH33-36B 3068771
XC16-024-230 + TXV 26,200 16.70 13.00 CR33-30/36 G60DFV-36A-070 3068808
XC16-024-230 + TXV 26,600 17.20 13.50 CR33-30/36 G60DFV-36B-090 3068809
XC16-024-230 + TXV 26,200 16.70 13.20 CR33-30/36 G61MPV-36B-045 3068810
XC16-024-230 + TXV 26,200 16.70 13.20 CR33-30/36 G61MPV-36B-070 3068811
XC16-024-230 + TXV 26,200 16.70 13.20 CR33-30/36 G61MPV-36B-071 3068813
XC16-024-230 + TXV 26,200 16.70 13.20 CR33-30/36 G71MPP-36B-070 3068812
XC16-024-230 + TXV 25,400 14.50 11.70 CR33-30/36 3068766
XC16-024-230 + TXV 25,200 15.70 12.70 CX34-18/24 CBWMV-24B-040 3496087
XC16-024-230 + TXV 25,400 16.50 12.70 CX34-18/24 G60UHV-36A-070 3493257
XC16-024-230 + TXV 24,800 14.20 11.50 CX34-18/24 3493256
XC16-024-230 + TXV 25,400 16.50 12.70 CX34-19 G60UHV-36A-070 3068776
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.

Lennox XC16 Specifications

General

SEER Rating	Up to 17.20
Cooling Capacity	1.5 to 5 tons
Sound Level	As low as 72 dB
Energy Star Certified	Yes
Refrigerant	R-410A
Warranty	10-Year Limited Warranty on compressor and parts
Compressor	Single-stage
