Lennox XC16 User Manual

XC16 - 2 to 5 Ton Heat Pump / Page 11
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-024-230 + TXV 24,800 14.20 11.50 CX34-19 3068761
XC16-024-230 + TXV 25,800 16.50 13.00 CX34-25 G60UHV-36A-070 3068777
XC16-024-230 + TXV 26,000 16.70 13.20 CX34-25 G60UHV-36B-090 3068778
XC16-024-230 + TXV 26,000 16.50 13.00 CX34-25 G61MPV-36B-045 3068779
XC16-024-230 + TXV 25,800 16.50 13.00 CX34-25 G61MPV-36B-070 3068780
XC16-024-230 + TXV 25,800 16.50 13.00 CX34-25 G71MPP-36B-070 3068781
XC16-024-230 + TXV 25,200 14.20 11.70 CX34-25 3068762
XC16-024-230 + TXV 25,200 16.00 12.70 CX34-30 G60UHV-36A-070 3068782
XC16-024-230 + TXV 25,200 16.00 12.70 CX34-30 G60UHV-36B-090 3068783
XC16-024-230 + TXV 25,200 15.70 12.50 CX34-30 G61MPV-36B-045 3068784
XC16-024-230 + TXV 25,200 15.70 12.70 CX34-30 G61MPV-36B-070 3068785
XC16-024-230 + TXV 25,200 16.00 12.50 CX34-30 G61MPV-36B-071 3068787
XC16-024-230 + TXV 25,000 16.00 12.70 CX34-30 G61MPV-36C-090 3068844
XC16-024-230 + TXV 25,200 15.70 12.70 CX34-30 G71MPP-36B-070 3068786
XC16-024-230 + TXV 25,000 16.00 12.70 CX34-30 G71MPP-36C-090 3068845
XC16-024-230 + TXV 26,200 16.70 13.20 CX34-31 G60UHV-36A-070 3068788
XC16-024-230 + TXV 26,400 17.00 13.50 CX34-31 G60UHV-36B-090 3068789
XC16-024-230 + TXV 26,400 16.70 13.20 CX34-31 G61MPV-36B-045 3068790
XC16-024-230 + TXV 26,200 16.70 13.20 CX34-31 G61MPV-36B-070 3068791
XC16-024-230 + TXV 26,400 16.70 13.20 CX34-31 G61MPV-36B-071 3068793
XC16-024-230 + TXV 26,200 16.70 13.20 CX34-31 G71MPP-36B-070 3068792
XC16-024-230 + TXV 25,600 14.50 12.00 CX34-31 3068763
XC16-024-230 + TXV 25,200 15.50 12.70 CX34-36 CBWMV-24B-040 3493247
XC16-024-230 + TXV 25,800 16.50 13.00 CX34-36 G60UHV-36A-070 3068794
XC16-024-230 + TXV 25,800 16.70 13.20 CX34-36 G60UHV-36B-090 3068795
XC16-024-230 + TXV 25,800 16.50 13.00 CX34-36 G61MPV-36B-045 3068796
XC16-024-230 + TXV 25,800 16.50 13.00 CX34-36 G61MPV-36B-070 3068797
XC16-024-230 + TXV 25,800 16.50 13.00 CX34-36 G61MPV-36B-071 3068799
XC16-024-230 + TXV 25,600 16.50 13.20 CX34-36 G61MPV-36C-090 3068800
XC16-024-230 + TXV 25,800 16.50 13.00 CX34-36 G71MPP-36B-070 3068798
XC16-024-230 + TXV 25,600 16.50 13.20 CX34-36 G71MPP-36C-090 3068801
XC16-024-230 + TXV 24,600 13.70 11.50 CX34-36 3068764
XC16-024-230 + TXV 26,400 17.00 13.20 CX34-38 G60UHV-36A-070 3068802
XC16-024-230 + TXV 26,600 17.00 13.50 CX34-38 G60UHV-36B-090 3068803
XC16-024-230 + TXV 26,600 16.70 13.20 CX34-38 G61MPV-36B-045 3068804
XC16-024-230 + TXV 26,400 17.00 13.20 CX34-38 G61MPV-36B-070 3068805
XC16-024-230 + TXV 26,600 17.00 13.20 CX34-38 G61MPV-36B-071 3068807
XC16-024-230 + TXV 26,400 17.00 13.20 CX34-38 G71MPP-36B-070 3068806
XC16-024-230 + TXV 25,400 14.20 11.70 CX34-38 3068765
XC16-036-230 + TXV 34,400 15.50 11.20 C33-36 CBWMV-36C-090 3184066
XC16-036-230 + TXV 34,200 15.00 11.00 C33-36 G60UHV-36A-070 3069103
XC16-036-230 + TXV 34,600 15.70 11.50 C33-36 G60UHV-36B-090 3069104
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.

Lennox XC16 Specifications

General

SEER Rating	Up to 17.20
Cooling Capacity	1.5 to 5 tons
Sound Level	As low as 72 dB
Energy Star Certified	Yes
Refrigerant	R-410A
Warranty	10-Year Limited Warranty on compressor and parts
Compressor	Single-stage
