XC16 - 2 to 5 Ton Heat Pump / Page 12
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-036-230 + TXV 35,000 16.00 11.50 C33-36 G60UHV-60C-090 3069105
XC16-036-230 + TXV 34,800 15.70 11.50 C33-36 G60UHV-60C-110 3069106
XC16-036-230 + TXV 34,200 15.20 11.00 C33-36 G61MPV-36B-045 3069107
XC16-036-230 + TXV 34,400 15.50 11.00 C33-36 G61MPV-36B-070 3069108
XC16-036-230 + TXV 34,200 15.20 11.00 C33-36 G61MPV-36B-071 3069110
XC16-036-230 + TXV 34,200 15.50 11.50 C33-36 G61MPV-36C-090 3069111
XC16-036-230 + TXV 34,400 15.50 11.00 C33-36 G71MPP-36B-070 3069109
XC16-036-230 + TXV 34,200 15.50 11.50 C33-36 G71MPP-36C-090 3069112
XC16-036-230 + TXV 33,800 13.70 10.70 C33-36 3069097
XC16-036-230 + TXV 35,600 15.70 11.50 C33-38 G60UHV-36A-070 3069113
XC16-036-230 + TXV 35,800 16.20 11.70 C33-38 G60UHV-36B-090 3069114
XC16-036-230 + TXV 35,600 16.00 11.20 C33-38 G61MPV-36B-045 3069115
XC16-036-230 + TXV 35,400 16.00 11.50 C33-38 G61MPV-36B-070 3069116
XC16-036-230 + TXV 35,400 16.00 11.50 C33-38 G61MPV-36B-071 3069118
XC16-036-230 + TXV 35,400 16.00 11.50 C33-38 G71MPP-36B-070 3069117
XC16-036-230 + TXV 34,600 14.00 10.90 C33-38 3069098
XC16-036-230 + TXV 34,400 15.70 11.50 C33-42 G60UHV-36B-090 3069119
XC16-036-230 + TXV 34,200 15.20 11.00 C33-42 G61MPV-36B-045 3069120
XC16-036-230 + TXV 34,000 15.20 11.00 C33-42 G61MPV-36B-070 3069121
XC16-036-230 + TXV 34,000 15.20 11.00 C33-42 G61MPV-36B-071 3069123
XC16-036-230 + TXV 34,000 15.20 11.00 C33-42 G71MPP-36B-070 3069122
XC16-036-230 + TXV 33,800 13.70 10.70 C33-42 3069099
XC16-036-230 + TXV 35,800 16.00 11.70 C33-43 CBWMV-36C-090 3184068
XC16-036-230 + TXV 36,000 16.20 12.00 C33-43 G60UHV-36B-090 3069124
XC16-036-230 + TXV 36,600 16.50 12.00 C33-43 G60UHV-60C-090 3069125
XC16-036-230 + TXV 36,000 16.50 12.00 C33-43 G60UHV-60C-110 3069096
XC16-036-230 + TXV 35,600 16.00 11.50 C33-43 G61MPV-36B-045 3069126
XC16-036-230 + TXV 35,400 16.00 11.50 C33-43 G61MPV-36B-070 3069127
XC16-036-230 + TXV 35,400 16.20 12.00 C33-43 G61MPV-36C-090 3069129
XC16-036-230 + TXV 36,200 16.20 12.00 C33-43 G61MPV-60C-090 3069131
XC16-036-230 + TXV 36,200 16.20 11.70 C33-43 G61MPV-60C-091 3069133
XC16-036-230 + TXV 36,200 16.00 12.00 C33-43 G61MPV-60C-110 3069134
XC16-036-230 + TXV 36,200 16.20 12.00 C33-43 G61MPV-60C-111 3069136
XC16-036-230 + TXV 35,400 16.00 11.50 C33-43 G71MPP-36B-070 3069128
XC16-036-230 + TXV 35,400 16.20 12.00 C33-43 G71MPP-36C-090 3069130
XC16-036-230 + TXV 36,200 16.20 12.00 C33-43 G71MPP-60C-090 3069132
XC16-036-230 + TXV 36,200 16.00 12.00 C33-43 G71MPP-60C-110 3069135
XC16-036-230 + TXV 35,200 14.20 11.00 C33-43 3069100
XC16-036-230 + TXV 36,000 16.20 12.00 C33-44C G60UHV-60C-090 3068758
XC16-036-230 + TXV 35,800 16.20 11.70 C33-44C G60UHV-60C-110 3068697
XC16-036-230 + TXV 35,200 16.00 11.70 C33-44C G61MPV-36C-090 3068698
XC16-036-230 + TXV 35,600 16.20 11.70 C33-44C G61MPV-60C-090 3068700
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.

Lennox XC16 Specifications

General

SEER Rating	Up to 17.20
Cooling Capacity	1.5 to 5 tons
Sound Level	As low as 72 dB
Energy Star Certified	Yes
Refrigerant	R-410A
Warranty	10-Year Limited Warranty on compressor and parts
Compressor	Single-stage
