Lennox XC16 User Manual

XC16 - 2 to 5 Ton Heat Pump / Page 13
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-036-230 + TXV 35,800 16.00 11.50 C33-44C G61MPV-60C-091 3068702
XC16-036-230 + TXV 35,600 15.70 11.70 C33-44C G61MPV-60C-110 3068703
XC16-036-230 + TXV 35,600 16.20 11.70 C33-44C G61MPV-60C-111 3068705
XC16-036-230 + TXV 35,200 16.00 11.70 C33-44C G71MPP-36C-090 3068699
XC16-036-230 + TXV 35,600 16.20 11.70 C33-44C G71MPP-60C-090 3068701
XC16-036-230 + TXV 35,600 15.70 11.70 C33-44C G71MPP-60C-110 3068704
XC16-036-230 + TXV 35,400 16.20 11.70 C33-48 G60UHV-36B-090 3069137
XC16-036-230 + TXV 36,000 16.20 11.70 C33-48 G60UHV-60C-090 3069138
XC16-036-230 + TXV 35,800 16.20 11.70 C33-48 G60UHV-60C-110 3069139
XC16-036-230 + TXV 35,200 15.70 11.20 C33-48 G61MPV-36B-045 3069140
XC16-036-230 + TXV 35,000 15.70 11.50 C33-48 G61MPV-36B-070 3069141
XC16-036-230 + TXV 35,200 15.70 11.20 C33-48 G61MPV-36B-071 3069143
XC16-036-230 + TXV 35,200 16.00 11.70 C33-48 G61MPV-36C-090 3069144
XC16-036-230 + TXV 35,600 16.00 11.70 C33-48 G61MPV-60C-090 3069146
XC16-036-230 + TXV 35,800 16.00 11.50 C33-48 G61MPV-60C-091 3069148
XC16-036-230 + TXV 35,600 15.70 11.70 C33-48 G61MPV-60C-110 3069149
XC16-036-230 + TXV 35,600 16.00 11.70 C33-48 G61MPV-60C-111 3069151
XC16-036-230 + TXV 35,000 15.70 11.50 C33-48 G71MPP-36B-070 3069142
XC16-036-230 + TXV 35,200 16.00 11.70 C33-48 G71MPP-36C-090 3069145
XC16-036-230 + TXV 35,600 16.00 11.70 C33-48 G71MPP-60C-090 3069147
XC16-036-230 + TXV 35,600 15.70 11.70 C33-48 G71MPP-60C-110 3069150
XC16-036-230 + TXV 34,800 14.20 10.90 C33-48 3069101
XC16-036-230 + TXV 35,600 14.50 11.00 C33-49 3069102
XC16-036-230 + TXV 34,800 14.70 11.20 CB26UH-030 3069152
XC16-036-230 + TXV 35,200 14.70 11.20 CB26UH-036 3069153
XC16-036-230 + TXV 35,000 15.70 11.70 CB27UH-036-230 3069157
XC16-036-230 + TXV 36,000 16.50 12.00 CB27UH-042-230 3069158
XC16-036-230 + TXV 34,200 15.00 11.00 CB30M-31P 3069154
XC16-036-230 + TXV 34,400 14.70 11.00 CB30M-41P 3069155
XC16-036-230 + TXV 34,600 14.70 11.20 CB30M-46P 3069156
XC16-036-230 + TXV 34,800 14.70 11.20 CBX26UH-030 3068746
XC16-036-230 + TXV 35,200 14.70 11.20 CBX26UH-036 3068747
XC16-036-230 + TXV 35,000 15.70 11.70 CBX27UH-036-230 3068754
XC16-036-230 + TXV 36,000 16.50 12.00 CBX27UH-042-230 3068755
XC16-036-230 + TXV 34,200 15.00 11.00 CBX32M-030 3068748
XC16-036-230 + TXV 34,400 14.70 11.00 CBX32M-036 3068749
XC16-036-230 + TXV 34,600 14.70 11.20 CBX32M-042 3068750
XC16-036-230 + TXV 34,400 15.50 11.20 CBX32MV-024/030 3068751
XC16-036-230 + TXV 35,000 16.00 11.50 CBX32MV-036 3068752
XC16-036-230 + TXV 36,000 16.50 12.00 CBX32MV-048 3068753
XC16-036-230 + TXV 34,400 15.50 11.20 CBX40UHV-030 3291635
XC16-036-230 + TXV 35,000 16.00 11.50 CBX40UHV-036 3291687
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.

Lennox XC16 Specifications

General

SEER Rating	Up to 17.20
Cooling Capacity	1.5 to 5 tons
Sound Level	As low as 72 dB
Energy Star Certified	Yes
Refrigerant	R-410A
Warranty	10-Year Limited Warranty on compressor and parts
Compressor	Single-stage
