Lennox XC16 User Manual

XC16 - 2 to 5 Ton Heat Pump / Page 14
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-036-230 + TXV 36,000 16.50 12.00 CBX40UHV-042 3291711
XC16-036-230 + TXV 36,000 16.50 12.00 CBX40UHV-048 3291797
XC16-036-230 + TXV 34,400 15.50 11.50 CH23-41 G61MPV-36B-070 3068714
XC16-036-230 + TXV 34,200 13.70 10.80 CH23-41 3068640
XC16-036-230 + TXV 34,600 14.00 10.90 CH23-65 3068641
XC16-036-230 + TXV 33,800 15.00 11.00 CH33-36A G60UHV-36A-070 3068715
XC16-036-230 + TXV 32,600 13.00 10.30 CH33-36A 3068642
XC16-036-230 + TXV 34,000 15.70 11.50 CH33-36B G60UHV-36B-090 3068716
XC16-036-230 + TXV 33,800 15.20 11.00 CH33-36B G61MPV-36B-045 3068717
XC16-036-230 + TXV 33,800 15.20 11.20 CH33-36B G61MPV-36B-070 3068718
XC16-036-230 + TXV 33,800 15.20 11.20 CH33-36B G61MPV-36B-071 3068720
XC16-036-230 + TXV 33,800 15.20 11.20 CH33-36B G71MPP-36B-070 3068719
XC16-036-230 + TXV 33,800 13.70 10.70 CH33-36B 3068643
XC16-036-230 + TXV 35,400 16.20 11.70 CH33-36C G60UHV-60C-090 3068759
XC16-036-230 + TXV 35,200 16.00 11.70 CH33-36C G60UHV-60C-110 3068721
XC16-036-230 + TXV 35,000 15.70 11.50 CH33-36C G61MPV-36C-090 3068722
XC16-036-230 + TXV 35,000 15.70 11.50 CH33-36C G71MPP-36C-090 3068723
XC16-036-230 + TXV 34,200 14.00 10.80 CH33-36C 3068644
XC16-036-230 + TXV 35,400 16.00 11.50 CH33-42 G60UHV-36B-090 3068724
XC16-036-230 + TXV 34,800 15.50 11.20 CH33-42 G61MPV-36B-045 3068725
XC16-036-230 + TXV 34,800 15.50 11.20 CH33-42 G61MPV-36B-070 3068726
XC16-036-230 + TXV 34,800 15.50 11.20 CH33-42 G61MPV-36B-071 3068728
XC16-036-230 + TXV 34,800 15.50 11.20 CH33-42 G71MPP-36B-070 3068727
XC16-036-230 + TXV 34,600 14.20 10.90 CH33-42 3068645
XC16-036-230 + TXV 36,200 16.20 12.00 CH33-43B G60UHV-36B-090 3068729
XC16-036-230 + TXV 35,800 16.00 11.50 CH33-43B G61MPV-36B-045 3068730
XC16-036-230 + TXV 36,200 16.00 11.50 CH33-43B G61MPV-36B-070 3068731
XC16-036-230 + TXV 36,000 16.00 11.50 CH33-43B G61MPV-36B-071 3068733
XC16-036-230 + TXV 36,200 16.00 11.50 CH33-43B G71MPP-36B-070 3068732
XC16-036-230 + TXV 35,800 14.50 11.00 CH33-43B 3068646
XC16-036-230 + TXV 36,600 16.50 12.00 CH33-43C G60UHV-60C-090 3068734
XC16-036-230 + TXV 36,400 16.50 12.00 CH33-43C G60UHV-60C-110 3068735
XC16-036-230 + TXV 35,400 16.20 12.00 CH33-43C G61MPV-36C-090 3068736
XC16-036-230 + TXV 35,400 14.50 11.00 CH33-43C 3068647
XC16-036-230 + TXV 35,400 16.00 11.70 CH33-44/48 G60UHV-36B-090 3068737
XC16-036-230 + TXV 35,200 15.70 11.50 CH33-44/48 G61MPV-36B-045 3068738
XC16-036-230 + TXV 35,200 15.70 11.50 CH33-44/48 G61MPV-36B-070 3068739
XC16-036-230 + TXV 35,200 15.70 11.50 CH33-44/48 G61MPV-36B-071 3068741
XC16-036-230 + TXV 35,200 15.70 11.50 CH33-44/48 G71MPP-36B-070 3068740
XC16-036-230 + TXV 35,200 14.20 11.00 CH33-44/48 3068648
XC16-036-230 + TXV 35,200 14.20 11.00 CH33-48 3068649
XC16-036-230 + TXV 36,400 16.50 12.00 CH33-48C G60UHV-60C-090 3068742
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.

Lennox XC16 Specifications

General

SEER Rating	Up to 17.20
Cooling Capacity	1.5 to 5 tons
Sound Level	As low as 72 dB
Energy Star Certified	Yes
Refrigerant	R-410A
Warranty	10-Year Limited Warranty on compressor and parts
Compressor	Single-stage
