Lennox XC16 User Manual

XC16 - 2 to 5 Ton Heat Pump / Page 15
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-036-230 + TXV 36,200 16.50 12.00 CH33-48C G60UHV-60C-110 3068743
XC16-036-230 + TXV 35,600 16.20 11.70 CH33-48C G61MPV-36C-090 3068744
XC16-036-230 + TXV 35,600 16.20 11.70 CH33-48C G71MPP-36C-090 3068745
XC16-036-230 + TXV 34,600 15.20 11.00 CR33-30/36 G60DFV-36A-070 3068706
XC16-036-230 + TXV 34,600 15.70 11.50 CR33-30/36 G60DFV-36B-090 3068707
XC16-036-230 + TXV 34,400 15.20 11.00 CR33-30/36 G61MPV-36B-045 3068708
XC16-036-230 + TXV 34,400 15.50 11.20 CR33-30/36 G61MPV-36B-070 3068709
XC16-036-230 + TXV 34,200 15.50 11.00 CR33-30/36 G61MPV-36B-071 3068711
XC16-036-230 + TXV 34,600 15.50 11.50 CR33-30/36 G61MPV-36C-090 3068712
XC16-036-230 + TXV 34,400 15.50 11.20 CR33-30/36 G71MPP-36B-070 3068710
XC16-036-230 + TXV 34,600 15.50 11.50 CR33-30/36 G71MPP-36C-090 3068713
XC16-036-230 + TXV 34,200 14.00 10.70 CR33-30/36 3068638
XC16-036-230 + TXV 34,000 13.70 10.70 CR33-48 3068639
XC16-036-230 + TXV 34,400 15.50 11.20 CX34-36 CBWMV-36C-090 3184067
XC16-036-230 + TXV 34,200 15.00 11.00 CX34-36 G60UHV-36A-070 3068650
XC16-036-230 + TXV 34,600 15.70 11.50 CX34-36 G60UHV-36B-090 3068651
XC16-036-230 + TXV 35,000 16.00 11.50 CX34-36 G60UHV-60C-090 3068756
XC16-036-230 + TXV 34,800 15.70 11.50 CX34-36 G60UHV-60C-110 3068652
XC16-036-230 + TXV 34,200 15.20 11.00 CX34-36 G61MPV-36B-045 3068653
XC16-036-230 + TXV 34,400 15.50 11.00 CX34-36 G61MPV-36B-070 3068654
XC16-036-230 + TXV 34,200 15.20 11.00 CX34-36 G61MPV-36B-071 3068656
XC16-036-230 + TXV 34,200 15.50 11.50 CX34-36 G61MPV-36C-090 3068657
XC16-036-230 + TXV 34,400 15.50 11.00 CX34-36 G71MPP-36B-070 3068655
XC16-036-230 + TXV 34,200 15.50 11.50 CX34-36 G71MPP-36C-090 3068658
XC16-036-230 + TXV 33,800 13.70 10.70 CX34-36 3068632
XC16-036-230 + TXV 35,600 15.70 11.50 CX34-38 G60UHV-36A-070 3068659
XC16-036-230 + TXV 35,800 16.20 11.70 CX34-38 G60UHV-36B-090 3068660
XC16-036-230 + TXV 35,600 16.00 11.20 CX34-38 G61MPV-36B-045 3068661
XC16-036-230 + TXV 35,400 16.00 11.50 CX34-38 G61MPV-36B-070 3068662
XC16-036-230 + TXV 35,400 16.00 11.50 CX34-38 G61MPV-36B-071 3068664
XC16-036-230 + TXV 35,400 16.00 11.50 CX34-38 G71MPP-36B-070 3068663
XC16-036-230 + TXV 34,600 14.00 10.90 CX34-38 3068633
XC16-036-230 + TXV 34,400 15.70 11.50 CX34-42 G60UHV-36B-090 3068665
XC16-036-230 + TXV 34,200 15.20 11.00 CX34-42 G61MPV-36B-045 3068666
XC16-036-230 + TXV 34,000 15.20 11.00 CX34-42 G61MPV-36B-070 3068667
XC16-036-230 + TXV 34,000 15.20 11.00 CX34-42 G61MPV-36B-071 3068669
XC16-036-230 + TXV 34,000 15.20 11.00 CX34-42 G71MPP-36B-070 3068668
XC16-036-230 + TXV 33,800 13.70 10.70 CX34-42 3068634
XC16-036-230 + TXV 35,800 16.00 11.70 CX34-43 CBWMV-36C-090 3184069
XC16-036-230 + TXV 36,000 16.20 12.00 CX34-43 G60UHV-36B-090 3068670
XC16-036-230 + TXV 36,600 16.50 12.00 CX34-43 G60UHV-60C-090 3068671
XC16-036-230 + TXV 36,000 16.50 12.00 CX34-43 G60UHV-60C-110 3068631
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.

Lennox XC16 Specifications

General

SEER Rating	Up to 17.20
Cooling Capacity	1.5 to 5 tons
Sound Level	As low as 72 dB
Energy Star Certified	Yes
Refrigerant	R-410A
Warranty	10-Year Limited Warranty on compressor and parts
Compressor	Single-stage
