XC16 - 2 to 5 Ton Heat Pump / Page 16
AHRI SYSTEM MATCHES
NOTE - For the latest up-to-date system matches please visit the AHRI web site at http://www.ahridirectory.org
Model
No.
Capacity SEER EER
Coil or
Air Handler
Furnace
AHRI
Reference
XC16-036-230 + TXV 35,600 16.00 11.50 CX34-43 G61MPV-36B-045 3068672
XC16-036-230 + TXV 35,400 16.00 11.50 CX34-43 G61MPV-36B-070 3068673
XC16-036-230 + TXV 35,400 16.20 12.00 CX34-43 G61MPV-36C-090 3068675
XC16-036-230 + TXV 36,200 16.20 12.00 CX34-43 G61MPV-60C-090 3068677
XC16-036-230 + TXV 36,200 16.20 11.70 CX34-43 G61MPV-60C-091 3068679
XC16-036-230 + TXV 36,200 16.00 12.00 CX34-43 G61MPV-60C-110 3068680
XC16-036-230 + TXV 36,200 16.20 12.00 CX34-43 G61MPV-60C-111 3068682
XC16-036-230 + TXV 35,400 16.00 11.50 CX34-43 G71MPP-36B-070 3068674
XC16-036-230 + TXV 35,400 16.20 12.00 CX34-43 G71MPP-36C-090 3068676
XC16-036-230 + TXV 36,200 16.20 12.00 CX34-43 G71MPP-60C-090 3068678
XC16-036-230 + TXV 36,200 16.00 12.00 CX34-43 G71MPP-60C-110 3068681
XC16-036-230 + TXV 35,200 14.20 11.00 CX34-43 3068635
XC16-036-230 + TXV 35,400 16.20 11.70 CX34-44/48 G60UHV-36B-090 3068683
XC16-036-230 + TXV 36,000 16.20 11.70 CX34-44/48 G60UHV-60C-090 3068757
XC16-036-230 + TXV 35,800 16.20 11.70 CX34-44/48 G60UHV-60C-110 3068684
XC16-036-230 + TXV 35,200 15.70 11.20 CX34-44/48 G61MPV-36B-045 3068685
XC16-036-230 + TXV 35,000 15.70 11.50 CX34-44/48 G61MPV-36B-070 3068686
XC16-036-230 + TXV 35,200 15.70 11.20 CX34-44/48 G61MPV-36B-071 3068688
XC16-036-230 + TXV 35,200 16.00 11.70 CX34-44/48 G61MPV-36C-090 3068689
XC16-036-230 + TXV 35,600 16.00 11.70 CX34-44/48 G61MPV-60C-090 3068691
XC16-036-230 + TXV 35,800 16.00 11.50 CX34-44/48 G61MPV-60C-091 3068693
XC16-036-230 + TXV 35,600 15.70 11.70 CX34-44/48 G61MPV-60C-110 3068694
XC16-036-230 + TXV 35,600 16.00 11.70 CX34-44/48 G61MPV-60C-111 3068696
XC16-036-230 + TXV 35,000 15.70 11.50 CX34-44/48 G71MPP-36B-070 3068687
XC16-036-230 + TXV 35,200 16.00 11.70 CX34-44/48 G71MPP-36C-090 3068690
XC16-036-230 + TXV 35,600 16.00 11.70 CX34-44/48 G71MPP-60C-090 3068692
XC16-036-230 + TXV 35,600 15.70 11.70 CX34-44/48 G71MPP-60C-110 3068695
XC16-036-230 + TXV 34,800 14.20 10.90 CX34-44/48 3068636
XC16-036-230 + TXV 35,600 14.50 11.00 CX34-49 3068637
XC16-048-230 + TXV 45,500 15.00 11.70 C33-44C G60UHV-60C-090 1003984
XC16-048-230 + TXV 45,500 14.70 11.50 C33-44C G61MPV-60C-090 1003983
XC16-048-230 + TXV 45,500 14.50 11.50 C33-44C G61MPV-60C-110 1003988
XC16-048-230 + TXV 45,500 14.70 11.20 C33-44C G61MPV-60C-091 1046650
XC16-048-230 + TXV 45,500 14.50 11.50 C33-44C G61MPV-60C-111 1046651
XC16-048-230 + TXV 45,500 14.50 11.50 C33-44C G71MPP-60C-110 1488411
XC16-048-230 + TXV 46,000 15.00 11.70 C33-48 G60UHV-60C-090 1003987
XC16-048-230 + TXV 45,500 15.00 11.70 C33-48 G60UHV-60C-110 1003990
XC16-048-230 + TXV 45,500 14.50 11.50 C33-48 G61MPV-60C-110 1003986
XC16-048-230 + TXV 45,000 14.20 11.20 C33-48 O23V5-140/154 1038249
XC16-048-230 + TXV 45,500 13.70 11.20 C33-48 1003999
XC16-048-230 + TXV 45,500 14.70 11.20 C33-48 G61MPV-60C-091 1046652
XC16-048-230 + TXV 45,500 14.50 11.50 C33-48 G61MPV-60C-111 1046653
NOTES:
+ TXV = Matched with Thermostatic Expansion Valve.
Ratings are certied in accordance with USE certication program which is based on AHRI Standard 210/240; 95°F outdoor air temperature, 80°F db / 67°F wb entering
evaporator air with 25 ft. of connecting refrigerant lines.
All ratings include the use of a blower time delay relay (TDR). All Lennox variable-speed furnaces and Air Handlers have time delay capabilities. Other Furnaces and Air
Handlers may require an optional time delay relay (58M81) for eld installation. See furnace or air handler specications to determine if relay is needed.
Also see TXV Substitutions Table.

Lennox XC16 Specifications

General

SEER Rating	Up to 17.20
Cooling Capacity	1.5 to 5 tons
Sound Level	As low as 72 dB
Energy Star Certified	Yes
Refrigerant	R-410A
Warranty	10-Year Limited Warranty on compressor and parts
Compressor	Single-stage
